Fully automatic high speed warping and sizing combination machine

Product Overview

Description

This Fully automatic  high speed warping and sizing combination machine is mainly used for cotton sample production and it is easy to change the design and variety. It is better for new design trial warping and sizing weaving beam.

Tenical Data

(1) Working width: 1800-4500(as youe requirements)

(2) Drum diameter:1026mm

(3) Cone angle: 9°(1:6.3)

(4) Cone length:1010mm (for beam flangeφ800mm)

(5) Outer warp jitter: ≤0.10mm

(6) Dynamic balance: accord with GB9239 standard 6.3 grade

(7) Speed:0~150m/min

(8)Warping operation table traversing  servo motor:1.5kw Delta

(9) Warping motor: 3kw

(10) Section traverse speed: 0.001~9.999mm/r

(11) Traverse deviation: ±0.01mm

(12) Stripe&start point location:automatic

(13) Section width: 0-400mm(it can be customized.)

(14) Drum brake:4pcs clamp brake

(15) Brake distance : ≤3m (when speed is 80m/min)

(16) Beaming tension control: pneumatic regulate damping

(17) Display: 10.4inch colorful touch screen Delta

 beaming machine

 (1)Type: whole beaming machine

 (2) Motor:18.5KW three phase asynchronous motor

 (3) Beaming speed: 0~100m/min

 (4) Beaming tension: 0~8000N

 (5) Speed deviation: ≤±1m

 (6) Beam brake: pneumatic, steel tape brake

 (7)Loading&doffing beam: pneumatic, air valve

 (8)Beaming safety: safety bar

Established in 2002, our company is specialized in designing, manufacturing and marketing of warping machine for many years. We have two branch companies now.

Our main products are warping machines and spares, mesh apron for spining machine.

As for the details you can reference www.yj628.com. We are gold member of alibaba, you can search “Jiangyin city Youbang Textile Machinery” from alibaba then you can see us.

Our group has passed ISO9001.The products must meet the technical standards of 3C and CE.

 All the products are certified by the Industry Administration Authority. We are enjoying an excellent reputation in the world market with perfect products and low price.

       Welcome to make inquiry!

You are warmly welcome to visit our factory!
