BS11 1985 Standard BS90A steel rail

Product Overview

Description

BS11-1985 Standard BS90A steel rail

EN13674-1 45E1 rail



This type of rail usually is used in English country, such as England, Europe, India, Bangladesh and Pakistan etc.

This rail is used in mining plant and low speed railway line, most is used for factory railroad line.

We have some stock of this rail, if the required quantity more than 400 tons, we can specially produce it for you, the length can be 12-25 meters.



Rail Type	Rail Height	Flange Width	Head Width at Top	Head Width at Base	Head Height	Web Thickness	Flange Thickness at Edge	Flange Thickness at Center	Weight (per meter)
	RH	FW	HT	HB	HH	WT	FE	FM	kg
BS 75A rail	128.6	114.3	61.9	63.75	30.5	12.7	8.3	15.48	37.46
BS 90A rail	142.9	127	66.7	68.83	33.5	13.9	9.1	17.07	45.10
BS 100A rail	152.4	133.35	69.85	72.14	35.81	15.08	9.52	16.27	50.18

Our products had passed through the inspection of Lloyd's regiester, any data all be qualified. If you are interested, please contact us to get the certificate 3.2.
