Water Disinfection High Power Germicidal 265nm UVC LED
US $1.00-$10.00
365nm 385nm 395nm high power UV led 1w 3W curing system
- Category: UV LED >>>
- Supplier: Shenzhen Yingfeng Opto-Electronic Co. Ltd.
Share on (60790138404):
Product Overview
Description
| Order Code | Current (mA) | VF (V) | Peak wavelength (nm) | Radiation Intensity (mW/Sr) | Radiant Power (mW) | Angle (Degree)
| Half Width (nm) |
| HYF38G30N365AG-D1 | 500 | 3.5-4.0 | 365-370 | 636 | 500-600 | 120 | 11 |
| HYF38X43B380AG-S1 | 700 | 3.0-3.6 | 380-390 | 2536 | 1100-1600 | 30 | 10 |
| HYF38X43B400AG-S1 | 700 | 3.0-3.6 | 395-405 | 2277 | 1000-1500 | 30 | 17 |
| HYF38X43B365AG-S1 | 700 | 3.5-4.0 | 365-370 | 2620 | 1100-1600 | 30 | 9 |
| HYF38X43B365AG-D1 | 700 | 3.5-4.0 | 365-370 | 1621 | 1100-1600 | 120 | 9 |
| HYF38X43B380AG-D1 | 700 | 3.0-3.6 | 380-390 | 1322 | 1100-1600 | 120 | 11 |
| HYF38X43B400AG-D1 | 700 | 3.0-3.6 | 395-405 | 1333 | 1100-1500 | 120 | 13 |
| HYE38X43B365AG-D1 | 700 | 3.0-3.6 | 365-370 | 426 | 1100-1600 | 120 | 9 |
| HYF38X56B365AG-S1 | 700 | 3.0-3.6 | 365-370 | 2808 | 2000-2500 | 30 | 9 |
| HYF38X56B365AG-D1 | 700 | 3.0-3.6 | 365-370 | 1856 | 2400-2800 | 120 | 9 |
Warmth Hint: The company is willing to personalize your customized products.
