Теплопроводящий центробежный циркуляционный насос YONJOU LQRY для теплового масла/растительного масла/сырой нефти

Product Overview

Description





Summarize:



1.YONJOU LQRY Series horizontal or vertical high temperature 370 degree hot oil transfer pump is suitable for heat-conduction oil, or other hot oils with temperature ≤370°C

2. It has a reasonable structure, advanced technology, high efficiency, long-term stable operation without leakage in the hot state. Used to transport not containing solid particles of corrosion high temperature liquid with system of directly wind cooling.

3. It's widely used in petroleum oil, chemical industry, rubber, leather, food industry, grease, boilers, construction, road maintenance, pharmaceutical, plastics, rubber, synthetic fiber textile, printing and dyeing and other industrial fields.







Product details:

Working Principle:	Centrifugal Pump
Material:	Cast Steel, SS304
Max. Temperature:	370°C(698°F)
Diameter Size:	20~150 mm
Flow Range:	4.5~400 m3/h (other request can be customized)
Head Range:	15~85 m (other request can be customized)
Usage:	Hot Oil, Cooling Oil, Circulation Oil
Drive:	Electric Motor, Diesel Engine
Liquid with Solid:	No







Performance Data:



Model	Capacity	Head	Speed	Shaft Power	Motor Power
	m3/h	m	r/min	kW	kW
26-20-100	4.5	15	2825	0.45	0.75
50-32-150	8	22	2900	1	1.5
50-32-160	10	25	2900	1.5	2.2
65-40-160	12.5	25	2900	2.5	3
50-50-170	12.5	32	2900	3.2	4
65-50-180	32	32	2900	4.5	5.5
65-50-170	40	25	2900	4.5	5.5
80-50-180	40	40	2900	6.7	7.5
80-50-170	60	20	2900	6.7	7.5
100-65-190	60	38	2930	9.2	11
100-65-200	80	40	2930	12.5	15
100-65-220	58	50	2930	12.5	15
100-65-230	100	55	2940	19.5	22
125-100-190	155	30	2940	20	22
100-65-240	100	70	2950	25.5	30
100-65-257	100	80	2950	32.5	37
125-100-220	160	45	2950	25.5	37
125-80-250	150	60	2970	35.5	45
125-100-257	200	60	2970	42.8	55
125-100-260	260	70	2970	64.3	75
