Why choose BENXU?
♦ Focus on Sensor Production all the time
♦ The Best Quality with Reasonable Factory Directly Price
♦ Have Passed CE,RoHS etc Certificates
♦ 18 Months Quality Guarantee Starting from the Date of Delivery
Do you care about followings after place an order?
♦ Quality problem?
BENXU signs the 18 months warranty of quality with you.
♦ Price problem?
If think price is higher at same top quality by comparison with others,we will refund you.
♦ After sale problem?
Artificial damage:will offer technical support.
Quality problem:will do repair or offer replacement without any cost within 18 months.
♦ Can’t deliver in time or some other problems?
Go ahead with Trade Assurance Online:

Applications:
Water treatment system and air compressor;
Medical treatment and agriculture machine;
Mechanical and electronic automation;
Pneumatic and hydraulic system;
Engineering equipment and test equipment.
Characters:
1,Setting upper and lower limit value and alarm point by your requirements;
2,Relay signal output to avoid the device operate invalidly frequently;
3,Have longer life time by comparison with traditional mechanism switch;
4,Nice controlling accuracy,anti-vibration,strong anti-jamming ability and fast response;
5,Easy to connect the wires and install;
6,Control the pressure in time with 4 digit LED display;
7,It can keep all setting when the power cut off;
8,Will work for pressure cycle 100000 times.
Technical Parameters:
|
Pressure Range |
0 to -0.1Mpa |
|
Accuracy |
0.5%FS |
|
Power Supply |
12VDC;24VDC;220VAC;380VAC(Optional) |
|
Alarm Point Setting |
Can set any point in the full scale |
|
Output Signal |
1 Relay output (upper limit disconnect,lower limit contact) |
|
Overload Capacity |
150%FS |
|
Long-term Stability |
0.5%FS/year |
|
Pressure Unit |
Mpa;kgf/cm2;PSI |
|
Overload Capacity |
380V 3A; 220V 5A; 24V 5A |
|
Using Temperature |
-20℃ to 80℃ |
|
Compensation Temperature |
-10℃ to 60℃ |
|
Electrical Protection |
Short-circuit protection;reverse protection;anti-electromagnetic interference |
|
Sampling Frequency |
5 times/second |
|
Measurement Medium |
Which is compatible with stainless steel |
|
Installation Connection |
G1/2;G1/4;NPT1/4;NPT1/8 etc;Stainless steel |
|
Connection Wires |
Power(red and blue);Output(black and white) |
|
Case Material |
ABS engineering plastic |
|
Sensor Chip |
Ceramic pressure sensor Core |
Dimensional Drawing(unit:mm):

Control Process and Line Definition:

Electrical Connection Diagram:


BENXU—a technical corporation with own research and development team,focus on production and sales for quality products of pressure/level/weighing/temperature measurement all the time.

1:What detailed information do I need to provide if I want to place an order?
application,measured medium,work temp.,test range,output,screw port,electrical connection etc.
2:How long will get the reply?
Contact you in 6 hours during working days or talk online through TradeManager,Skype,Wechat.
3:Could I get samples?
Any quantity samples are available for you to test our quality.
4:Could you provide me the shortest lead time?
We have materials in stock,we will put your order ahead of schedule if need in rush.
5:Could I visit your factory?
Of course,we warmly welcome you to visit our factory.
6:What’s the terms of payment?
Paypal or Western Union for samples,TT or LC for bulk order.
7:How could you control the quality?
100% incoming quality control for materials,process inspection when produce,and then do long-term test for temperature compensation,aging test,long-term stability performance etc if need,and then final inspection before leaving the factory.
8:Can we use our logo on the products?
Yes,we can provide OEM/ODM service and make your laser logo.
9:What's the means of transport?
DHL/FEDEX/UPS/EMS/TNT/China Post/Sea etc. Freight prepaid or Freight collect.
