1.5 Inch Very Small Lcd Screen JHD144B2605
US $0.01-$1.00
with lg open cell 65inch 2000cd/m2 open frame 4K vending machine tft lcd panel module
- Category: LCD Module >>>
- Supplier: Shenzhen Fengshi Technology Co. Ltd.
Share on (60808358337):
Product Overview
Description
High Brightness
With a great brightness of max 5,000 cd/㎡ , the KT series clearly delivers contents and attracts public attention, which is the ultimate display for outdoor visibility.
Long Lasting Brightness
Visible with Polarized Sunglasses
By adding more LED units, KT series operates brighter at a lower temperature, thereby lasting longer than conventional products.
High Temperature LCD
Work normally in direct sunlight. Combined with a high Tni110℃ industrial grade OC, the KT series can operate 24/7.
Thanks to its thin depth, the KT series takes up less space, which leads to space efficiency and mounting friendly in any outdoor signage cabinet or enclosure.
Smart Brightness Control
The auto brightness sensor and preset time scheduler save power consumption and protect viewer's eyes by adjusting the brightness automatically according to the embient brightness.
Support Multi-
Input Method
Parameter
Items | Specification | Unit | Note |
Active Screen Size | 65 | inch | Diagonal |
Display Area | 1428.48（H）*803.52（V） | mm | |
Outline Dimension | 1461.0(H)*843.1(V)*88.0 (D) | mm | |
Driver Element | a-Si TFT active matrix | ||
Display Colors | 1.07B | colors | |
Color Gamut | 68 | % | NTSC |
Number of Pixels | 3840*2160 | Pixel | |
Pixel Arrangement | RGB | ||
Pixel Pitch | 0.630*0.630 | mm | |
Display Mode | Normally Black | ||
Surface Treatment | Haze 28% , 2H | ||
Brightness | 2000 | nits | |
Power | 550 | W | |
Zoom | 16:09 | ||
Working temperature | 0--50 | ℃ | |
Weight | 25 | kg | |
Back light life | 50000 | hr |
Applications
Quality Control
Certifications
Packing&Shipping
FAQ
1. Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in LCD panel/LCM since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements. In order to support different
customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA, DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.
4. Q: What brand of screen do you use?
A: Original LG/SAMSUNG/AUO etc. screen, we can guarantee each display will pass through strict quality inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity & the RLSM028BD report, ISO certification, FCC certification, UL certification.
6. Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black over 110℃.
7. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
8. Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
A: We are a professional manufacturer specialized in LCD panel/LCM since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements. In order to support different
customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA, DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.
4. Q: What brand of screen do you use?
A: Original LG/SAMSUNG/AUO etc. screen, we can guarantee each display will pass through strict quality inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity & the RLSM028BD report, ISO certification, FCC certification, UL certification.
6. Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black over 110℃.
7. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
8. Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
