Main features
« DB-15 KVM with 4 port /8port /16ports in 1U.
« Support all computers to both boot and hot-swappable.
« Cascade switched up to 4 / 8 / 16 levels and Mix switches DB-15 KVM switch .
« USB , SUN&MAC with Multi-platform switch capability
Specification
Model | KVM - 1004M | KVM - 1008M | KVM - 1016M | |
computer connection | Direct : 4 | Direct : 8 | Direct : 16 | |
computer connection | MAX : 128 | MAX : 256 | MAX : 512 | |
Connection port | Control port : Display , keyboard & Mouse | |||
PC port : USB port | ||||
OSD Switch | Support | |||
Switch Mode | Hotkey, OSD menu | |||
Switch scan time | 1~255 sec ( adjustable by OSD ) | |||
Pre-electronic key | To select the appropriate server through electronic key | |||
Input | AC 100V~240V 47-63Hz Power :1W | |||
Cabinet material | high strength and anti-corrosive rigid plate | |||
Color | Insulated black paint ( Optional ) | |||
Dimension | 180mm x 438mm x 44mm | |||
Package | 550mm x 230mm x 145mm , 550mm x 330mm x 145mm | |||
Weight | About 6KG | |||
Environment | Storage Temp | -30℃ ~ 65℃ | ||
Operating Temp | -10℃ ~ 60℃ | |||
Humidity | 0%~95% | |||
Certificated | CE , FCC , RoHS , CCC | |||
Ordering information
| KVM - 1004M | 1U Rack mount KVM switch, W/ 4 VGA port , W/ 12V power supply |
| KVM - 1008M | 1U Rack mount KVM switch, W/ 8 VGA port , W/ 12V power supply |
| KVM - 1016M | 1U Rack mount KVM switch, W/ 16 VGA port , W/ 12V power supply |



12-48hours UV Test before shippment

Shenzhen Pontron Technology Ltd we have dedicated in Industrial panel pc,Industrial LCD monitor,KVM, Industrial BOX pc,workstation,Mini pc in the worldwide market for 10 years. our products has the CE/EMC/FCC/ROHS certificate and the customers are all over the world.especially in USA, Europe, Australia and Asia.
Our dedicated team of engineers, production specialists, and administrative staff provide the best quality products available on the market.
We pride ourselves on our expertise in producing customized products. Through ODM/OEM production, you are assured of designs which will meet your exact specifications. Our innovative ideas in manufacturing which will make your products a leading seller on the market. this results in short period of develpoment time for projects.
In PONTRON, we have a qualified working team which includes senior level mechanical and electronic R&D engineers, OEM product/sales manager, ISO 9001 trained manufacturing personel, and an efficient logistics department. we have an average age of 30 years old, and the average working experience in the industrial computer field is more than 7 years.
PONTRON, is committed in prooviding quality, innovative products and technical support to our customers in a very cost effective manner. we like to grow with our customers.we believe customer satisfaction is the key to our growth and success. we work for your needs and your satisfaction is guaranteed.
