Vehicle parameters

Vehicle Model

EHY5160GXFSGQ

Vehicle Brand

ISUZU

Overall dimensions

8360X2485X3420mm

Curb weight

9700kg

Water tank volume

5500L

Chassis parameters

Chassis model

QL1180XMFRY

Chassis brand

ISUZU

Overall dimensions

7570×2490×2810mm

Wheel base

4500mm

Front/rear wheel track

1960/1855mm

Front/rear suspension

1335/2225mm

Approach/departure angle

15/17°

Maximum speed

95km/h

Chassis Manufacturer

QingLing Motors (Group) Co., Ltd.

Cab

Configuration

FVR,double rows cab,allowable 3+3 passengers,with air conditioner, central locking, electric windows, USB audio, cab can be flipped.

Color

Red,other color is optional

Engine

Model

6HK1-TCL

Emission

Euro 5

Type

6 cylinders, in-line, 4-stroke, Exhaust gas turbo, air-to-air inter-cooling, diesel engine

Rated power

240hp

Displacement

7790ml

Manufacturer

Isuzu Engine (Chongqing) Co., Ltd.

Tire

Size

295/80R22.5 tubeless tyre

Number

6+1 nos

Front axle

6.3 tons

Rear axle

13.0 tons

Drive form

4X2

Suspension

Multi leaf springs

Rated voltage

24V,DC

Transmissions

Isuzu MLD six speed transmission,6 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive

Selective configuration

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Upper-Body specification

Water tank

Volume

5500L

Material

high quality carbon steel plate, anti-rust treatment inside.

Fire fighting pump

Model

Shanghai Rongshen CB10/40

Max working pressure

1.251Mpa

Max allowable entrance pressure

0.4Mpa

Flux:

Water 40L/S

Suction depth

≥ 7m

Suction time

≤35s

Fire knozzle

Model:

Shandong Yunhu PS40

Range:

≥ 55m

working pressure

≤1.0(Mpa)

Horizontal rotation angle

360 º

color

The whole vehicle is red for fire fighting, there are white in the middle of truck in accordance with the whole truck
