Approval ISO putzmeister concrete pump with good price

Share on (60818389141):


Price:

Quantity:


Product Overview

Description


Approval ISO putzmeister concrete pump with good price

Product Description

 Concrete pump is a construction equipment which conveys concrete by pressure through pipeline. It is equipped with special pipeline. It can continuously complete horizontal and vertical conveyance of concrete along pipeline. It is an ideal kind of existing concrete conveyance equipment. It combines the production of ready-mixed concrete with pumping construction and uses coagulation. The soil mixing truck carries out intermediate operation, which can realize continuous pumping and pouring of concrete. It is used for conveying concrete in large concrete projects.320890678372573757.jpg784441451302262912.jpg




rated parameters:

itemparametersunit
Shape size5623×1884×2606mm
Whole machine quality5035kg
Concrete conveying capacity50m3/h
Maximum output pressure8Mpa
Conveying distance (vertical / horizontal)100/400m
Hopper volume / feeding height0.6/1320m3/mm
Concrete slump80-230mm
Concrete delivery bore diameter / stroke180/1400mm
Active engine-diesel engine
ModelWP4G110E220
Rated power82kw
Rated speed2200r/min
Hydraulic system
typeopen
Hydraulic system pressure32Mpa
Main oil pump
Model typeA11VLO130
Rated working flow224L/min
Pump cylinder diameter / stroke 90/1400 mm
 Hydraulic tank volume250  L





Packaging & Shipping




Company Information

 .jpg



Certifications




FAQ

Q1:Which country do you export to?

Asia:India,Philippines,Thailand,Burma,Vietnam,Bangladesh,Kazakhstan,Turkmenistan,etc.

Middle east:Saudi Arabia,Iran,UAE,Jordan,Oman,Syria,Pakistan,etc.

Europe:Russia,Ukraine,Belarus,Bulgaria,etc.

Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc.

South America:Brazil,Peru,Chile,Cuba,Venezuela,Mexico,etc.

Oceania:Papua New Guinea,Australia,etc.

Q2:What is the proportion of your products export?

75% of our products are exported to all over the world.

Q3:What is the payment term?

Payment term is negotiable and there will be favorable payment terms for long-term customers.TT,L/C,D/P,depending on the cooperation time,country and contract value.

Q4:What kind of logistic service do you supply?

FOB,CIF,DAP,ETC.

Q5:What spare parts can you supply?

All kinds of spare parts of xcmg,shantui,zoomlion,sinotruck,shacman,liugong,sany,sdlg,lonking,xgma,etc.

Contact







Our Factory welcomes your visit very much.

If you are interested in our products, you can send us an inquiry. Let's be friends. You will be surprised._08.jpg
