Best price high quality underground shovel diesel scooptram 1.5cbm
- Category: Other Mining Machines >>>
- Supplier: Shandong Tongwu Machinery Equipment Co. Ltd.
Share on (60819779804):
Product Overview
Description
CE Certification 1.5cbm scooptram underground diesel made in China
Product Description
CY-15 1.5 CBM Diesel LHD (2.1M Dumping)
Feature&Benefits
1. Power system adopts YTO turbo-charged engine, big power, low emissions.
2. Using technology leader slewing structure, hydraulic steering, rear axle swing compared to traditional forms, lower failure rate, easy to maintain.
3. Walk system uses hydraulic torque converter, power shift transmission, and improve reliability.
4. Operating system adopts pilot control, making the operation more simple work, work more efficiently.
5.Exhaust system is equipped with imported purifier water filtration system, greatly reducing air pollution.
6. Vehicle chassis plate thickening, enhanced vehicle steel bucket shovel blade made of high strength alloy steel, wear resistance to shear, V-type structure, reducing scooping resistance and longer life.
7. Adopt 12.00-24 puncture resistant smooth rubber tires.
8. Working brake is air over hydraulic oil wet type brake, parking brake is air over hydraulic oil caliper disc brake, the brake is safe and reliable.
9. The machine can be shoveling, loading, transport, unloading one operation, compact structure, convenient operation, high efficiency operation for recovery of mines and tunneling mucking, and workplace and road construction formation, transport of materials and other auxiliary operations.
Specifications
CY-15 | |
Main specifications | |
Bucket capacity (m3 ) | 1.5 |
Rated load (t) | 3.0 |
Weight (t) | 10.0 |
Lifting time of the arms (s) | ≤4 |
The sum of three items(s) | ≤9 |
Forward gear(km/h) | I 0-9.5 II 0-28.5 |
Reverse gear | I 0- 12.8 |
Max. climbing gradient | 20° |
Dimensions | |
Overall dimension (mm) | 6450×1600×2100 |
Wheel base (mm) | 2750 |
Wheel tread(mm) | 1270 |
Max. dumping height(mm) | 2100 |
Dumping reach (mm) | 1085 |
Diesel engine | |
Engine model | YTO LR4M3Z-22 |
Engine type | In-line,water-cooling,4-stroke, 4 cylinders, direct-injection |
Rated power(kw) | 81/92 |
Rated speed (r/min) | 2200/2200 |
Total exhaust of cylinder(L) | 4.5/3.9 |
Type of starting | Electric start |
Transmission system | |
Torque converter |
|
Model | China LIUGONG BS205 |
Type | Single stage, three elements |
Gearbox |
|
Model | China LIUGONG BS205 |
Type | Planetary power shift |
Axle and tire | YUNYU CY30S |
Type of main reducer | Spiral bevel gear,single stage |
Type of final reducer | Single stage planetary |
Size of tire | 12.00-24 |
Working device of hydraulic system | |
Model of working pump | CBG2100 |
Nominal displacement(ml/r) | 100 |
Rated pressure(Mpa) | 12.5 |
Multi-way directional valve | DF32.2 |
Pressure(Mpa) | 20 |
Rated flow(L/min) | 250 |
Steering system | |
Type | Load-sensing hydraulic steering |
Displacement(ml/r) | 400 |
Max input pressure(Mpa) | 16 |
Brake system | |
Type of traveling brake | Air over hydraulic oil wet type brake |
Type of parking brake | Air over hydraulic oil caliper disc brake |
