Fluorocarbon high/low temperature resistance/ medium resistance compound
- Category: Fluorocarbon Rubber >>>
- Supplier: Chengdu Eson New Material Co. Ltd.
Share on (60872991282):
Product Overview
Description
Product Description
Fluorocarbon Rubber high/low temperature resistance/ medium resistance compound
| Chengdu Eson FKM Fluoroelastomer | |||||||||||
| Grade | Polymer properties | Mechanical Properties | Description / Features | Typical Uses | |||||||
| Viscosity | Color | Gravity | Fluorine Content | TR10 | Tensile | Elongation | Hardness | Compression Set | |||
| ML(1+10)@121℃ | g/cm3 | % | ℃ | Mpa | % | Shore A | ASTM D395 Method B(70hrs@200C) | ||||
| Fluoroelastomer Compounds O-rings/Gaskets/Oil Seals Application | |||||||||||
| FA-H2604 | Any | 1.90 | 66 | -17 | 12.5 | 250 | 60 | 18 | To meet Aerospace Specifications DTD5612A and DTD5543B Grade 60 | General purpose,O-rings,gaskets,extrudes hoses/profiles | |
| FB-H2603 | Any | 1.93 | 68 | -13 | 11.5 | 260 | 62 | 31 | Low hardness,Superior resistance to heat chemical media than standard copolymer | General purpose,O-rings,gaskets,extrudes hoses/profiles | |
| FA-H2701 | Any | 1.92 | 66 | -17 | 13.5 | 220 | 70 | 15 | Excellent mold flow,mold release and compression set resistance | O-rings,gaskets | |
| FB-K2753 | Any | 2.05 | 68 | -13 | 12.7 | 260 | 75 | 30 | Superior resistance to heat and chemical media than standard copolymer | General purpose,O-rings,gaskets,extrudes hoses/profiles | |
| FA-H2804 | Any | 1.93 | 66 | -17 | 15 | 210 | 80 | 17 | To meet Aerospace Specifications DTD5612A and DTD5543B Grade 80 | General purpose,O-rings,gaskets,extrudes hoses/profiles | |
| FA-H2851 | Any | 1.97 | 66 | -17 | 16.1 | 170 | 84 | 16 | Excellent rheology,mold release and good compression set resistance | O-rings,gaskets | |
| FB-H2853 | Any | 1.97 | 68 | -13 | 14.8 | 220 | 85 | 30 | Superior resistance to heat and chemical media than standard copolymer | General purpose,O-rings,gaskets,extrudes hoses/profiles | |
| FA-H2904 | Any | 1.95 | 66 | -17 | 16 | 160 | 90 | 18 | To meet Aerospace Specifications DTD5612A and DTD5543B Grade 90 | O-rings,gaskets | |
| Fluoroelastomer Compound for Automotive turbochargers | |||||||||||
| ESHT35P | 1.91 | 70 | 21 | 260 | 70 | 35 | Good flowability, excellent extrudability/good adhesion with MOQ | Extrusion or by hand molding | |||
| ESH25P | 1.84 | 67 | 18.5 | 230 | 69 | 25 | |||||
| Fluoroelastomer Compounds Oil Hose/Extruded Hose Application | |||||||||||
| FA-H2602 | Any | 1.90 | 66 | -17 | 12 | 310 | 60 | 20 | Low hardness,high elongation/tear strength,bonding to metal property | Extruded hoses/profiles.Oil seals and complicated geometries | |
| FA-K2652 | Any | 2.01 | 66 | -17 | 11.8 | 290 | 65 | 19 | Low hardness,high elongation/tear strength,bonding to metal property | Extruded hoses/profiles.Oil seals and complicated geometries | |
| FA-H2752 | Any | 1.93 | 66 | -17 | 14.2 | 280 | 75 | 18 | Excellent mold flow,high elongation/tear strength,bonding to metal property | Extruded hoses/profiles.Oil seals and complicated geometries | |
1.Where is your factory and how can we visit it?
Our factory is located in Jiangsu province and welcome all customers visit us from your airpot to Shanghai airport and take 2 hours train to our factory.
2.What is the features of FKM material?
FKM is famous for heat resistance, chemical resistance, oil resistance d etc.
3.What types FKM compound are you supply?
We can supply A, B, F, GBL, GF, GLT, ETP, TBR types of FKM Compound.
4.What hardness is populer?
Based on the application and end product size and different processing method customer chose 60-90 Shore A FKM compound.
5.What is the processing method of your FKM Compounds?
Molding, extrusion, transfer, Calendering, bonding , injection materials are avaiable.
6.Can you OEM for us?
Yes no problem for us.
7.How can we get customized material?
According to required typical properties and using-environment we can R & D for you.
8.What is the shift time for the FKM compound?
Better use it within half years after produced.
9.What is the MOQ ?
20KG for one grade.
10.What color are you making?
Black, Brown, Green, Blue, Red, Grey or customized color.
11.Can we get the sample?
Yes, 0.2-0.5 free sample is fine for us and need you pay the express charge or collect the sample.
12.What is your delivery time?
2-7 working days after payment, customized product delivery time is based on the R & D progressing
13.How about the supply capacity?
If all raw materials have stock, 2T/day is not a problem for us.
