3 ton electric locomotive battery charger

Underground mine battery locomotive are designed for horizontal rail transport especially in mines and enclosed spaces. They are also intended for use in potentially explosive environment with coal dust and methane in volume up to 1.5 %. They can work on slopes of rail lines up to 35‰ , with track gauge from 500 to 1060 mm, at ambient temperatures from -20°C to +40°C.

Locomotives are with single cabin and two cabins weighing from 2.5 t to 18 t. Cabins are removable, due to a simple transport into underground tunnels. Transmission of torque moment from the electric motors is through the axle gearbox to travel wheels. The chassis is of dual-axle type and travel wheels are secured with interchangeable rims. Suspension of locomotive is provided by elastic rubber-metal blocks of sagittal shape or by means of springs in accordance with the track quality.

Specification

Specification for CJY3/6,7,9G battery locomotive
Name	Data	Remark
DC voltage	250V
Traction	13.05kn	1 hour system
Max traction	17.2KN
Motor hourly power	21KW*2	1 set
Speed	11KM/H	1hour
Gauge	600,762 or 900mm
Traction Force	13..06KN
MAX Traction Force	17.2kN
Minimum curvature radius	7M
Motor power* sets	21kw*2
Traction height	320mm
Length	4420mm
Width	1054,1216/1354mm
Height	1550mm
Wheelbase	1100mm
Wheel Diameter	Φ650mm
Way of Speed Control	Resistance or Chopped wave
Braking mode	Mechanism

Detailed Image

Frame.

Motor.

Gear

Aluminium roll .

More parts

Our advantage

1. Quick shipping, within 3 days.

2. Factory price.

3. Custom acceptable

4. 12 months of warranty

5. Support 7 days refund

6. Payment online

Our Company

Jining Huida Machinery CO., LTD, an ISO 9001-2015 and ISO 14001:2015 certificated company was founded in 1996 in Jining, Shandong province, manufacture machinery & equipment for mining equipment : mining wagon, mining locomotives, mining tools, mining truck....
With hundreds of machines in stock in our 5000 quare meters, and 22 years' experience in souring farm machinery.
We are a team of highly motivated individuals working together to fulfil our mission for miners 'to put what you need, within you reach'. We have contacts across the globe, we can source the machinery you need to ship anywhere in the world, Jining Huida have many satisfied customer thoughout more than 30 different counties.
