High Frequency fixed X ray Radiograph System, digital remote control X ray machine

Specifications

1.Fluoroscopic Capacity
 Max rated capacity           : Tube Current 4mA, Tube Voltage 110kV
 Automatic Fluoroscopy     : Tube Voltage:40kV~110kV Adjust  Automatically
                                   Tube Current  : 0.3mA~4mA set manually
 Manual Fluoroscopy          : Continuous Tube Voltage:40kV~110kV
                        Continuous Tube Current : 0.3mA~4mA
Pulse Fluoroscopy             : Continuous Tube Voltage 40kV~110kV
                                              Continuous Tube Current 4.1mA~8mA
2. Photography Capacity
 Max rated capacity             : 3.5 KW
 Tube Voltage and Current Combination  : 40kV~49kV   1 ~125 mAs
                                                50kV~59kV   1 ~110 mAs
                                                60kV~69kV   1 ~90  mAs
                                                70kV~79kV   1 ~80  mAs
                                                80kV~89kV   1 ~71  mAs
                                                90kV~99kV   1 ~63  mAs
                                                100kV~110kV 1 ~40  mAs
 Plateholder Size                 :  200mm×250mm(8″×10″)or
                                               250mm×300mm(10″×12″)
3.X-ray Tube
   X-ray Tube Special for High Frequency

 Fixed anode   Dual-focus : large focus: 1.5, small focus: 0.6

Inverter Frequency:  40KHz

Thermal capacity: 35KJ (47KHU)

4.VideoSystem
   Image Intensifier       : Image Intensifier made by TOSHIBA (9″, 6″,4.5″)
   CCD Vidicon              : Ultra low-light CCD camera imported from Japan
   Monitor                       : Horizontal 1000 lines and vertical 800 lines,
                                         Bandwidth : 12.5MHz,     Image/sec : 75

CCU(central control)         : Recursive Filter: K=8, 8 images storage,  image upright, image overturn,positive &negative image;LIH(last image freeze, and OSD(monitor display)

5.Structure:
 Directive wheel                  : ±90°revolution,can freely change the moving  direction of the unit.
 Ascending & Descending Range of Pillar             : ≥400mm
 C-arm                                : Forward and Backward Movement: 200mm
                                             Revolution around Horizontal Axis:  ±180°
                                              Revolution around Vertical Axis     :  ±15°( Advantage), better than others’  ±12.5°, easier  to take special positions radiography )
                                              Slip on orbit: 120°(+90°~ -30°)

I Usage:

Orthopaedics: osteopathy, diaplasis, nailing

Surgery: removing foreign body, cardiac catheter, implanting pace maker, interventional therapy, partial radiography, local photography, and other work.

II Features

1. New integrated design, compact appearance, convenient operation.;

2. Unique hand-held remote controller, more convenient operation

3. Graphical colorfully LCD touch screen console interface, convenient operation, fashionable design

4. High-quality combined HF-HV X-ray generator, greatly reducing the X-ray irradiation.

5. Toshiba image intensifier is employed, stable and reliable in quality , high-definition image and display system

6. With the perspective KV, MA automatic tracking feature, the image brightness and definition are automatically set at optimal function.

7. Medical high-resolution progressive output TV system, eight image storage, clearer image and convenient operation.

III Configuration

1, New (with electric auxiliary support arm) C-arm main rack     one set

2, High-frequency high-voltage X-ray generator and high-frequency inverter power supply(3.5KW,40KHZ,110KV)                             one set

3, Toshiba 9-inch image intensifier                            one set

4, 1 million pixel ultra-low-light digital cameras                  one set

5, high- definition progressive output CCU main-control system   one set

6, High-thickness grids                                    one set

7, Electric adjustable collimator                               one set

8, 23-inch high- definition medical monitor                      one set

9, Unique hand-held remote controller                         one set
