Светодиодный чип 0,2 нм 2835 нм SMD Вт ИК диод в упаковке
- Category: SMD LED >>>
- Supplier: Shenzhen Trillion Auspicious Lighting Co. Ltd.
Share on (62006443276):
Product Overview
Description
luminous diameter:2.8*3.5*0.8mm
the use of voltage:850NM 1.4-1.8V 940NM 1.2-1.4V
use current: 60ma
packing:4000pcs/reel
Power:0.2W
Wavelength:IR 845-855NM/940-945NM
product brightness:
2835 High Efficiency(0.2W )
Dimension | 2.8x3.5x0.8mm | |
Forward Voltage | 1.4-1.8V | 1.2-1.3V |
Power | 0.2w | |
Wavelength | 845-855NM
|
940-945NM |
Forward Current | 60MA
| 60MA
|
Chip Size | 14mil
| |
Monitoring distance | The monitoring distance is better within 150 meters.
| |
Infrared light is the abbreviation of night vision monitoring infrared light. It is a light-filling device that collects images at night with surveillance cameras. The light emitted by the infrared lamp has two wavelengths of 850 nm and 940 nm, all of which are invisible light. It has the characteristics of concealment and energy saving. It has been widely used in the field of security monitoring in the past 10 years.
The RZXLED 2835 series is an upgrade from standard 3528 packages. With a newly designed heat slug and compact design, this LED can be over driven while maintaining its compact size, high efficiency,and cost effectiveness. The superior product characteristics turn this white LED device into a real cost and energy saver and is a top solution for any general lighting application.
Applications
• Automotive Interior Lighting, Dashboard, Switch, Reading lamp, Audio and Car Infortainment, etc
• Backlight: LCD, switches, symbol, mobile phone and illuminated advertising.
• Optical indicator.
• General applications.
range of application:indoor lighting,commercial lighting,
Note:not waterproof,not more than load,cooling temperature is not
higher than sixty degrees
There are thousands of modules so we can't list all in our store.
Please contact us for check if you can't find in the store.
Thank you!
Note :
They may burn out if they receive enough power with no cooling , And if you use it for a long time,
please give them colling!!!
