DF 145 5ton 5000liters XDR water fire truck engine

XDR 6000liters water fire truck

Vehicle Parameters

General

Vehicle Model

YZR5140GXFSG50/E

Vehicle Brand

XDR

Chassis Brand

Dongfeng(EQ1108KJ)

Overall Dimension(mm)

7360×2480×3330

GVW/Curb Weight(kg)

13700/8050/5200

Chassis Parameters

Cab

Cab Seat

3+3

Air Conditioner

Optional

Engine

Fuel Type

diesel

Engie Model

B170 33

Engine Brand

Dongfeng Cummins

Power(kw/hp)

125/170

Displacement(cc)

5900

Emmission Standard

Euro3

Chassis

Drive Type

4*2

Transmission

6speed, Manual

Wheelbase(mm)

3950

Tyre Specification

9.00-20

Tyre No.(pcs)

6+1

Max Speed(km/h)

90

Paint

Red

Fire Truck Water Tank Structure Parameters

Tank Volume

5000-6000L

Tank Material

Carbon Steel

Tank Thickness

4/3/3mm

Fire pump

CB10/40

Fire monitor

PS40

Color and

Optional

Standard configuration

Chassis,sub frame, van body,national standard equipment box, 25 units national standard fire-fighting equipment,fire pump(CB10/20,
CB10/30,CB10/40,CB10/60 according to the capacity), fire gun(PS20,PS30,PS40,PS50 according to the capacity),fire power take off,
sliding gate, row type lights, reel, common tools,rear climbing ladder,water tank.
