CRI 98 LED 5050 smd led chip datasheet epistar chip 0.2w
- Category: SMD LED >>>
- Supplier: Shenzhen Huanyu Dream Technology Co. Ltd.
Share on (62036078423):
Product Overview
Description
Specification
CRI 98 LED 5050 smd led chip datasheet epistar chip 0.2w
》》2835 5730 3030 5050 5054 SMD LED available
》》0.2W 0.5W 1W high power
》》3V 6V 9V 12V 18V 24V 36V 54V 72V as choose
》》Red Green Blue Amber White Pink etc customize color
》》Cri with Ra80 Ra90 Ra95 Ra98, customer made voltage,CCT
Model No. | HYZM-SMD5050W | Power | 0.2W | ||
Lumens | White:16-22LM Red:2000~2500mcd Yellow:2000~2500mcd Green:5000~6000mcd Amber/Gold yellow:20~22LM Pink:12~14LM Ice Blue:12~14LM Purple:1~2LM RGB:3000~3500MCD | ||||
Color Temp | White:2600-20000K Red:620~630nm Yellow:590~600nm Green:520~530nm Blue:460~470nm Purple:390~405nm Amber/Gold yellow: 1600~2000k | ||||
Voltage | W/G/B/Pink/Purple: 3.0~3.4v Red/Yellow: 2.0~2.4v | Current | W/R/G/B/Y/Pink: 60mA RGB: 20mA | ||
Chip Brand | Sanan,Epistar,Forepi | Chip Size | 9*26*3mil etc | ||
Lifespan | 50,000 hours | Warranty | 3 years | ||
Application
Related Products
Company Information
Certification
Customer Reviews
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 1-3 days, mass production time needs 3-7 days according order quantity .
Q3. Do you have any MOQ limit for led light order?What's the Payment way ?
A: MOQ is 100pcs for each model. We accept T/T Paypal and Western Union three ways payment.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
