TG180 Rebar Thread Rolling Machine/Screw Thread Rolling Machine/Used Thread Rolling Machine

Thread Rolling Machine TG180 is extrusion forming thread with rolling tools by cold rolling technology which is an advanced chip-free processing technology. The rolling process is continuous. It can effectively improve the surface cleanliness, hardness and strength of the workpiece through the rolling radial pressure. It has high working efficiency.

Within its cold rolling range the machine can roll, straighten, polish, shrink to form the workpieces into all kinds of threads like common threads, twill threads, straight threads, helical teeth, trapezoidal threads, modulus threads as you need.

The machine has safe and reliable electro-hydraulic performance and control system. The cycle of rolling process can be switched between manual and automatic as user's need.

Main Features

1.Cold rolling and chip-free processing

2.Form all kinds of threads as you need

3.High working efficiency

4.Safe and reliable electro-hydraulic performance and control system

5.Processing manual or automatic as you need

Parameter

Thread Rolling Machine TG180
Process Range	prcess type	DIA	Length	Pitch
	rolling one head or both 2 heads	8-60mm	≤140mm	≤5mm
	rolling the whole bar	8-42mm	no limited	≤4mm
Inner DIA of Roller	75mm
Outter DIA of Roller	170-210mm
Roller Width's range	30-150mm
Center distance of 2 rollers	122-225mm
Dip Angle of Main Shaft	±15°
Rotary Speed of Main Shaft	20,25,31,41,51,64r/min
Max rolling pressure	200Kn
Hydraulic auto feeding adjusted time	0.1-99.9s
Hydraulic cease time regulation range	0.1-99.9s
Main axis power	11kw
Hydraulic power	4.0kw
Dimensions	2200*1650*1450mm
Machine total weight	2200kg+50kg

Packing & Delivery

Packing Details :

Plastic bag and then fumigation-free wooden case.

Delivery:

within 5 days after if machine is in stock;
producing according to customers' order within 10-25 days

Our Service

Pre-Sale Service
1.Communicate about your actral use situation and help you to choose most suitable machine model
2. Design color,marks according to your requriy
3.Produce the machine according to your order

Sale Service
1.Check the machine upon delivery
2.Help you to make operating manual and precautions

After Service
1.Guarantee for a year.
2.Discuss the problem and send corresponding repair parts,if the machine has working problem
3.Free repair whole using life(without the freight and accessories charge).

FAQ

Q: Are you a factory or trading company?
A:We are a manufacturer with 10 years experience,you could get factory price from us.

Q:Where is your factory located? How can I visit?
A:Our factory is located in Ren Contry,Xingtai City,Hebei Province,China,about 3 hours from Beijing.We can pick up clients from Beijing Airport or Shijiazhuang Airport to visit us.

Q:Can you do OEM?
A:Yes,we do OEM machines.

Q:what is your payment terms?
A:Generally,30% in advance,70% before shipment.

Q:Can you provide installation service?
A:Yes,we can,but you need pay for the air tickets,hotel and food fee,and 50 USD/day.
