A: Increased munber of ports for installation flexibility
B:Modular air valve for stall-free ,low pulsation operation ,providing smooth and rapid changeover
C:Up to 5x longer diaphragm life for less maintenance and downtime
D:Four bolt joint design provides even sealing pressure for optimal performance
HY Air-Operated Diaphragm Pumps Selection
Technical parameters
Mode
Max.Suction Lift (dry\wet,m)
Max. particle diameter (mm)
Suction and discharge size (inch)
Air inlet size (inch)
Max. flow rate (L/min)
Max. air consumption (m3/min)
HY-15/20
4 \ 7.6
2.5
1/2 3/4
1/4
57
0.672
HY-25
4 \ 8
4
1
1/2
157
1.7
HY-40
5 \ 8
5
1½
1/2
358
3.5
HY-50
5 \ 8
6
2
1/2
587
4.9
HY-80
5 \ 8
9.4
3
3/4
1060
9.1
Performance curve
Model sheet
HY Air-Operated Diaphragm Pump Installation
HaoYang AODD pumps are suitable for an endless variety of applications . Our pumps can be deployed in fixed installations within a process flowsystem, or used as portable or mobile units that can be transported to where it is to be used.
Pump, self-priming HY AODD pumps are dry self-priming. Depending on the pump specification a suction lift of up to 8 m
Pump with positive suction Depending on the pump type, the suction side inlet pressure may need to be limited to a max. pressure
Pump, submerged HY AODD pumps can be totally submerged in the pumped medium. The exhaust outlet must remain above the fluid level.
Pump for drums HY AODD pumps can be directly mounted on drums or containers.
HY Air-Operated Diaphragm Pum Application
The air operated diaphragm pumps use compressed air as power source, and it is the most advanced type of diaphragm pumps in market for the moment. It adopts three-way air pilot valve to achieve real no dead stop and faster reversing. It is widely applied in waste water treatment, chemical industry, petrochemical industry, painting, ceramics, environmental protection, printing and dyeing, etc. to deal with all kinds of corrosive, volatile, flammable, poisonous fluids with particles and high viscosity.
spraying and cleaning
Air Operated Diaphragm pumps are perfect for spraying paint, cleaning roofs and spraying conveyers/bottles for anti-static. These pumps are suited for these types of applications due to their durability and the volume produced by each pump. The pump, combined with the power of an air compressor, allows cleaning chemicals, paints and other fluids to be dispensed at a constant rate.
Industrial and Chemical The selection of available housing and elastomer materials make our pumps adaptable for most highly aggressive or corrosive media. HY pumps’outstanding chemical resistance and robust design contribute to a reliable and safe operation.
Water treatment
Water treatment facilities pump huge amounts of water every day. A reliable pump that can stand up to continuous use is key to efficient operation. Our air-driven diaphragm pumps
have fewer parts and require less maintenance.
Company Information
HY Company information
Shanghai Haoyang Pump Valve Manufacturing Co., Ltd.designed and manufactured for over 10 years in Shanghai,China. HaoYang Air-Operated Double Diaphragm (AODD) pumps have earned industry recognition for premium quality and innovative design. And we supply accessories and components suitable for most AODD pump installations.To ensure suitability for a variety of media, wetted parts are available in numerous optional materials.
Focus on customer satisfaction is supported with quality and reliability, validated by CE certifications.We specify only the most durable materials that are dependable and long-lasting. When we combine the highest-quality products with topnotch customer care, we get outstanding value.
FAQ
FAQ
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: What're your payments ?
A: T/T,Western Union,L/C etc.
3. Q: What about the package ?
A: Standard export plywood case or carton.
4. Q: How long is the warranty ?
A: According to international standards, products in standard operation is 1 year,except wearable parts.
5. Q: The use of products have?
A: The pump can suck the peanut, pickles, tomato slurry, red sausage, chocolate, hops and syrup etc.
The pump can suck the paint, pigment, glue and adhesive etc.
The pump can suck various glazed slurries of tile, porcelain, brick and chinaware etc.
The pump can suck various toxin and flammable or volatility liquid etc.
The pump can suck various strong acid, alkali and corrosive liquid etc.
6. Q: How product quality and service?
A: Our pump have CE certificate, quality assured, can accept OEM, provide various personalized needs.
