360 Degree Rotating Pallet Spring Level Loader
- Category: Lift Tables >>>
- Supplier: I-Lift Equipment Ltd.(Wuxi)
Share on (62056548672):
Product Overview
Description
Product Description
Pallet &spring level loader is an ergonomic tool that is ideal for building or unpacking pallet loads. It can automatically
maintain a load at the ideal height for manual loading and unloading. This simple, automatic level loader uses a system of springs and shock absorbers to lower and raise loads as boxes are added or removed from pallets. No power or air supply is required, and it is virtually maintenance free! It features low-friction bearings for smooth operation. Full 360° access allows for nearside loading without reaching, as the operator can step closer to the unit's platform to add or remove pallet loads.
maintain a load at the ideal height for manual loading and unloading. This simple, automatic level loader uses a system of springs and shock absorbers to lower and raise loads as boxes are added or removed from pallets. No power or air supply is required, and it is virtually maintenance free! It features low-friction bearings for smooth operation. Full 360° access allows for nearside loading without reaching, as the operator can step closer to the unit's platform to add or remove pallet loads.
Model | QSL1000 |
Capacity kg(lb.) | 200-2000(440-4400) |
Compressed height mm(in.) | 240(9.4) |
Extended height mm(in.) | 710(28) |
Rotating ring, outside dia. mm(in.) | 1100(44) |
Rotating ring, inside dia. mm(in.) | 1035(40.7) |
Base frame length mm(in.) | 1150(45.3) |
Base frame width mm(in.) | 930(36.6) |
With 3 springs | Large, middle, small |
Option | Lift table mover |
Main Features of 360 Degree Rotating Pallet Spring Level Loader
* Automatically maintain a load at the ideal height for manual loading and unloading.
* Automatically maintain at the top of the load as the working height.
* Including a steel scissor lift mechanism and at least one large compression spring.
* The springs are chosen to match the weight and height of a fully loaded pallet.
* With a shock absorber to eliminate tendency if the load bounce on the springs.
* A turntable top allows nearside loading and unloading.
* Automatically maintain at the top of the load as the working height.
* Including a steel scissor lift mechanism and at least one large compression spring.
* The springs are chosen to match the weight and height of a fully loaded pallet.
* With a shock absorber to eliminate tendency if the load bounce on the springs.
* A turntable top allows nearside loading and unloading.
