2020 HYTB 1100 52KW Hot Sell Powder Hot Melt Glue Coating Machine
- Category: Coating Machines >>>
- Supplier: Ruian Benyue Machinery Co. Ltd.
Share on (62066311675):
Product Overview
Description
Products Description
Specifications.
HYTB-1100 hotmelt glue coating machine
Application:
HYTB-1100 hotmelt glue coating machine is widly used for label and adhesive tape ETC
HYTB-800 SILICONE OIL COATING MACHINE is mainly suitable for reel -type substrate coating production.The material such as :
,Opp CPP ,PET ,Bopp ,,ETC
Characteristics:
Unwinding frame:
1 Model: single station climbing type
2 effective unwinding width: 1100mm
3 unwinding dia. 1000mm
4 unwinding shaft : air shaft 2pc, machine shaft 1pc
5 unwinding tension control: 20kg magnetic powder brake, tension closed loop control
6 webguide: EPC auto-register
7 frame: cast iron, profiled bar
Humidification frame
1 humidification type: transfer type
2 effective coating width: 1100mm
3 humidification roller measure roller, humidification roller,
4 press roller by pneumatic execute
5 doctor blade frame: manual adjustment type and angle is adjust freely
6 ink pan stainless steel ink pan, manual lift type
7 drive reduction motor inverter by PLC control, 1set
8 cooling roller 320mm , surface plating hard chromium, mirror process
9 coating frame steel plate, profiled bar
Unwinding frame of laminating material:
1 Model: single station climbing type
2 effective unwinding width: 1100mm
3 unwinding dia. 1000mm
4 unwinding shaft : air shaft 2pc, machine shaft 1pc
5 unwinding tension control: 20kg magnetic powder brake, tension closed loop control
6 webguide: EPC auto-register
7 frame: cast iron, profiled bar
Coating frame (spray form)
1 hot melt heater heating method: electric heating, heating power 28kw, heating temperature is 50 degree-200degree,300kg capacity,
glue output is 150kg/hour, temperature is controlled by auto-controller, 1set
2 hot melt spray head: the head max. spray width 1100mm, spray quantity 13-30g per square meter,glue quantity is control by PLC,
spray head heating method is electric heating, power 7.6kw, with spray pipe, 1set
3 coating rubber roller dia. 215*1200mm, rubber is made of silicon gel, hardness shore 68-70 degree, 1pc
4 spray head clutch adopt pneumatic execute, with fine adjust device
5 traction steel roller dia. 415mm*1200mm, surface plating hard chromium, grinding accuracy process, 1pc
6 traction rubber press roller dia.215mm*1200mm, rubber is silicon gel, hardness is 68-70shore, 1pc
7 middle cooling steel roller with dia.320*1200mm, surface plating hard chromium, mirror process, 2pcs
8 coating rubber roller, traction steel roller, traction rubber press roller, middle cooling steel roller cooling adopt water cold
cycle type, with water rotation head
7 with water cooling machine , power 3p, 1set ( it should be provided by buyer)
9 middle transition guide wheel dia. 80*1150mm
11 drive reduction motor inverter by PLC control, 1set
12 traction wallboard is make of steel plate
13 with slitting trash edge function, with 2pcs air knife, wich blower 1set
Rewinding frame
1 frame: double station electromotion rotation and auto-splicing system
2 effective rewinding width 1100mm
3 effective rewinding diameter 1000mm
4 rewinding shaft 3inch air shaft 2pc
5 drive frequency motor by inverter control , 2set
Drive system
1 type: frequency motor, vector inverter by PLC control, motor with reducer
2 running form: 3units independent running
3 running form with 3units: A unwinding unit, B spray coating unit C rewinding system
4 control form: A overall machine tension control (unwinder, coating, traction, rewinding) adopt PLC system auto-control and
running with synchronous, each unit can control running independently, B overall machine subsection tension control, unwinding
tension auto-control system, during traction and rewinding by floating swing roller tension control system
MAIN PARAMETER
HYTB-1100 hotmelt glue coating machine
Application:
HYTB-1100 hotmelt glue coating machine is widly used for label and adhesive tape ETC
HYTB-800 SILICONE OIL COATING MACHINE is mainly suitable for reel -type substrate coating production.The material such as :
,Opp CPP ,PET ,Bopp ,,ETC
Characteristics:
Unwinding frame:
1 Model: single station climbing type
2 effective unwinding width: 1100mm
3 unwinding dia. 1000mm
4 unwinding shaft : air shaft 2pc, machine shaft 1pc
5 unwinding tension control: 20kg magnetic powder brake, tension closed loop control
6 webguide: EPC auto-register
7 frame: cast iron, profiled bar
Humidification frame
1 humidification type: transfer type
2 effective coating width: 1100mm
3 humidification roller measure roller, humidification roller,
4 press roller by pneumatic execute
5 doctor blade frame: manual adjustment type and angle is adjust freely
6 ink pan stainless steel ink pan, manual lift type
7 drive reduction motor inverter by PLC control, 1set
8 cooling roller 320mm , surface plating hard chromium, mirror process
9 coating frame steel plate, profiled bar
Unwinding frame of laminating material:
1 Model: single station climbing type
2 effective unwinding width: 1100mm
3 unwinding dia. 1000mm
4 unwinding shaft : air shaft 2pc, machine shaft 1pc
5 unwinding tension control: 20kg magnetic powder brake, tension closed loop control
6 webguide: EPC auto-register
7 frame: cast iron, profiled bar
Coating frame (spray form)
1 hot melt heater heating method: electric heating, heating power 28kw, heating temperature is 50 degree-200degree,300kg capacity,
glue output is 150kg/hour, temperature is controlled by auto-controller, 1set
2 hot melt spray head: the head max. spray width 1100mm, spray quantity 13-30g per square meter,glue quantity is control by PLC,
spray head heating method is electric heating, power 7.6kw, with spray pipe, 1set
3 coating rubber roller dia. 215*1200mm, rubber is made of silicon gel, hardness shore 68-70 degree, 1pc
4 spray head clutch adopt pneumatic execute, with fine adjust device
5 traction steel roller dia. 415mm*1200mm, surface plating hard chromium, grinding accuracy process, 1pc
6 traction rubber press roller dia.215mm*1200mm, rubber is silicon gel, hardness is 68-70shore, 1pc
7 middle cooling steel roller with dia.320*1200mm, surface plating hard chromium, mirror process, 2pcs
8 coating rubber roller, traction steel roller, traction rubber press roller, middle cooling steel roller cooling adopt water cold
cycle type, with water rotation head
7 with water cooling machine , power 3p, 1set ( it should be provided by buyer)
9 middle transition guide wheel dia. 80*1150mm
11 drive reduction motor inverter by PLC control, 1set
12 traction wallboard is make of steel plate
13 with slitting trash edge function, with 2pcs air knife, wich blower 1set
Rewinding frame
1 frame: double station electromotion rotation and auto-splicing system
2 effective rewinding width 1100mm
3 effective rewinding diameter 1000mm
4 rewinding shaft 3inch air shaft 2pc
5 drive frequency motor by inverter control , 2set
Drive system
1 type: frequency motor, vector inverter by PLC control, motor with reducer
2 running form: 3units independent running
3 running form with 3units: A unwinding unit, B spray coating unit C rewinding system
4 control form: A overall machine tension control (unwinder, coating, traction, rewinding) adopt PLC system auto-control and
running with synchronous, each unit can control running independently, B overall machine subsection tension control, unwinding
tension auto-control system, during traction and rewinding by floating swing roller tension control system
MAIN PARAMETER
Type | TB-1100 |
Effective coating width | 1100 |
Roller width | 1150mm |
Machine speed | 200m/min |
Work speed | 10-180m/min |
Max. Unwinding diameter of base material | 1000mm |
Max. Rewinding diameter | 1000mm |
Edge Trimness when rewinding | Accuracy ≤3mm |
Overall machine motor power | Approx 52kw |
Machine weight | Approx 10tons |
Diamension | 12.5m×2.8m×2.1 m |
