Aluminum case 10.1 inch RK3288 touch screen RJ45 RS232 industrial tablet with front rfid reader
Product Description
The specifications of Aosimai 10.1 inch industrial tablet with front rfid reader
System
CPU
RK3288
RAM
2GB
Internal memory
8GB
Operation system
Android 6.0
Touch
Touch screen
10-Point capacitive touch
Display
Panel
10.1"LCD IPS panel
Resolution
1280*800
Active area
216.96(H)x135.6mm(V)
Display mode
Normally black ,IPS
Viewing angle
80/80/80/80(L/R/U/D)
Contrast ratio
800:1
Luminance
300cd/m2
Aspect Ratio
16:10
Network
WiFi
802.11b/g/n
Ethernet
10M/100M ethernet
Bule-tooth
Blue-tooth 4.0
USB 2.0
2
HD-MI output
1
TFcard
1
RJ45
1
rs232
1
Power jack
DC power input
Media play
Video format
MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 1080p
Audio format
MP3/WMA/AAC etc.
jpeg
Other
Battery
N/A
VESA
75x75mm
Speaker
2*1.5W
Front Camera
2.0M pixel ( Face Recognition option )
Microphone
built-in
RFID reader
built-in RFID reader, IC / ID / etc. card
Working temp
0--50degree
Certificates
CE/FCC/RoHS
Key
POWER/VOL+/VOL-
Language
Multi-language
The Advantage of our Aosimai industrial tablet with front rfid reader:
1. Aluminum alloy brushed metal craft front bezel , seamless design, front panel IP65 waterproof and dustproof. 2. Industrial LCD panel, wide viewing angle, high nits, true color. 3. Adopt multi-points PCAP touch panel , high sensitive and fast-response. 4. High performance motherboard, 7x24 continuous operation. 5. Support wall mounting,embedded mounting,desk stand mouting etc. 6. Integrated with RFID reader and front face recognition camera.
7.Non-touch screen version is available.
Packaging & Shipping
Our Services
OEM / ODM service:
Multi-inputs optional: add CPU, USB, Speaker, Camera, Audio etc; Screen logo: add customized logo when power on; Frame logo: add customized logo on the design perfectly; Back label: add customized info on the back of the label; Serial number: add customized serial number on each box; Manual: make customized manual as requested; Color Box: add customized logo and info on the box; Carton: add customized marks on carton;
Appearance customization: support appearance design, sample customization;
System software customization: compatible with all software requirements;
I/O ports customization: support adding more according to requirements;
Wide voltage: 12v-24v;
Special materials: for special occasions;
IP grad: can be customized full - sealed dust-proof waterproof;
Screen size: support to customized screen.
Company Information
Shenzhen Aosimai Technology Co., Ltd. Is one of the largest LED monitor, industrial grade all in one PC, drawing monitor, advertising player in China.
1. We have more than 21 years production experience.
2. We have three automated production line.
3. Our products have got FCC,ROHS,CE,CCC,ISO certification approval.
4. We have two factories with an area of over 3500 square meters, one of our factory is located in Futian Free Trade Zone with an area of 1,500 square meters, we can enjoy the government's import and export tax exemption policy, so that we can provide customers with the high quality products at a price lower than the market average.
5. We only adopts brand new A+grade IPS / TFT LCD panel, and we have more than 10000 pieces screens in stock.
6. There is 2 engineers and 10 technicians in our company to deal with the tech problems.And we have QA staff team:20 people(IQC:3,IPQC:9,FQC:5,OQC:3). Let you buy our products without worry about after-sale service.
Quality Inspection:
FAQ
Q: Are you Manufacturer or trading company?
A: We are manufacturer with 100 staff, and more than 5 R&D engineers,
holding leading position in field for 21 years.
Q: whether your product support the oem / odm?
A: Yes, our monitor support the customization with size, function, appearance, resolution, high brightness and etc.
Q: Where is your product apply?
A: Restaruant, Advertisement, Gaming, Medical Equipment, kiosk, ATM, Industrial autamation, Supermarket chain stores etc.
Q: What is the delivery date after payment confirmed?
A: Regular order is 15-30 days delivery.
Q: Do you support Sample?
A: Yes, Sample order is available but it will be charged.
Q: What is the main size for your monitor?
A: 7" to 86’’, we also support the customized.
Q: Can we printing our logo on the housing? What is MOQ?
A: Except the opening logo, we can do the silk-printing LOGO in the case. MOQ is 200pcs and free charge.
Q: What kind of inspection you can provide?
A: Aosimai have multiple tests from material purchasing to finished products by different departments, like QA, QC, sales representative, to guarantee all monitors are in perfect condition before shipment. We also accept the inspection by the third party you appointed.
