RuiHe 98% Smoke Removal Rate Commercial Air Scrubber
- Category: Gas Disposal >>>
- Supplier: Dongguan Rui Zhaohe Environmental Protection Equipment Co. Ltd.
Share on (62078952076):
Product Overview
Description
Air pollution is cutting global life expectancy by an average of 1.8 years per person, making it the world’s top killer. While we cannot control outdoor air quality, we can choose to protect us and create a clean commercial kitchen. RUIHE Commercial kitchen Air Scrubber's mission is to create healthy indoor commercial kitchen for people.
WORKING PRINCIPLE
1. The dirty air first passes through a pre-filter. Large particles of oil are filtered.
2. The air then passes into the high voltage ionise section where the particulates are charged to a positive potential. And then the air passes into low voltage collector cell
section where the particulates are charged to a negative potential. So the particulates are attracted to the collector plates effectively.
3. The particulates remain on the plates or drain down in to the sump.
4. The cleaned air exits through the cabinet.
Commercial Air Scrubber Commercial Air Scrubber Commercial Air Scrubbe
DGRH-K Single Pass ESP parameter
| NO. | Model | Air Flow (CMH) |
Cabinet Size L*W*H (mm) |
Flange Size W*H(mm) |
Removal efficiency Rate |
Power (Watt) |
| 1 | DGRH-K-3500(U) | 3000-3500 | 640*765*690 | 485*530 | 93-98% | 110 |
| 2 | DGRH-K-7000(U) | 6000-7000 | 640*1300*690 | 1020*530 | 93-98% | 176 |
| 3 | DGRH-K-10500(U) | 9000-10500 | 640*1835*690 | 1560*530 | 93-98% | 242 |
| 4 | DGRH-K-14000(U) | 12000-14000 | 640*1300*1380 | 485*1210 | 93-98% | 330 |
| 5 | DGRH-K-21000(U) | 18000-21000 | 640*1835*1380 | 1020*1210 | 93-98% | 484 |
| 6 | DGRH-K-31500(U) | 27000-31500 | 640*1835*2070 | 1560*1890 | 93-98% | 726 |
Product Advantage
1. Odor, smoke, oil control efficiently
2. Modular in design: Modular units allow to vertical/horizontal stacking combination as per different air flow or removal efficiency rate request.
3. Intellegent electrostatic power control system
Electric intensity auto-control function ensures the Kitchen ESP Collector unit maintains a high purification rate after a long time service.
4. Photolysis and odor removal: High power UV tube will remove food odor more efficiently.
Do everything for you, would you like support my job ? tks.
Would you like protect the blue sky with DR AIRE ?
The First time choice for DR AIRE ESP, Forever Trust !
Welcome order. Please Send US Enquiry and get 2% discount now. Click Here tks
Dongguan Rui zhaohe Environmental Protection Equipment Co., Ltd is one of leading manufacturers in China,specialized in manfacturing commercial, industial air pollution control machines.
DR AIRE is our brand,main products: commercial kitchen electrostatic precipitator (ESP), mobile cooking station ,BBQ cart with Smoke filter, industrial Esp, ductless range hood, ,coffee Roasters smoke filter ,actived carbon filter, CNC oil mist collectorand etc
