Type 316 stainless steel has the best corrosion resistance among standard stainless steels. It resists pitting and corrosion by most chemicals, and is particular resistant to saltwater corrosion.
Thread
coarse, fine
Used
These can be used for a variety of applications.Sail boats and yachts, cable railing, and for shade sails.
Dimension
Size A
B
C
D
WLL
(mm)
(mm)
(inch)
(mm)
(mm)
(mm)
(kg)
4
4
5/32"
11
13
51
65
5
5
3/16"
13
13
59
135
6
6
1/4"
14
14
65
275
8
8
5/16"
19
19
92
500
10
10
3/8"
22
25
117
700
12
12
1/2"
32
33
152
1200
16
16
5/8"
38
41
187
2150
20
20
3/4"
41
51
216
3150
22
22
7/8"
47
51
235
3650
25
25
1"
64
65
279
4500
