XCMG Official XE215C Hot Sale Chinese New Excavator 20 Ton Crawler Excavator Price List
- Category: Excavators >>>
- Supplier: Xcmg E-Commerce Inc.
Share on (62089267891):
Product Overview
Description
\t\t\t\t\t\t\t\t\tProduct Description \t\t\t\t\t\t\t
XCMG Official XE215C Hot Sale Chinese New Excavator 20 Ton Crawler Excavator.
Main parameters:
Bucket capacity:0.93CBM (standard)
Main configuration:
ISUZU CC-6BG1TRP engine
Hydraulic system
XCMG XE215C is the most popular model of China 21t excavator,Now XE215C is upgrading to new model equipped with EURO III engine with electric injector, new model will have high performance.
1,High-end configuration·Excellent performance
XE215C is suitable for earth and stone construction projects such as municipal construction, highway bridges, housing construction, road engineering, farmland water conservancy construction, port construction and so on, it has features of good flexibility and maneuverability, low fuel consumption, high construction efficiency.
2,New generation·Environmental·Energy-saving·Large power engine
New generation environmental engine is adopted in this machine, which has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced.
Specification
Model | Parameters | |
Engine | Model | ISUZU CC-6BG1TRP |
Equipped | Electronic fuel injection | |
Four strokes | ||
Water cooling | ||
Turbo-charging | ||
Air to air intercooler | ||
No. of cylinders | 6 | |
Output power | 128.5/2100 kW/rpm | |
Torque/speed | 637/1800 N.m/rpm | |
Displacement | 6.494 L | |
Operation Weight | 21900 kg | |
Bucket Capacity | 0.9—1.0 m ³ | |
Main performance | Travel speed(H/L) | 5.5/3.3 km/h |
Rotating speed | 13.3 r/min | |
Gradeability | ≤35° | |
Ground pressure | 47.2 kPa | |
Bucket digging force | 149 kN | |
Arm digging force | 111 kN | |
Maximum traction | 184 kN | |
Hydraulic system | Main pump | 2 plunger pumps |
Rated flow of main pump | 2×209 L/min | |
Pressure of prime valve | 34.3/37.0 Mpa | |
Pressure of travel system | 34.3 Mpa | |
Pressure of swing system | 28 Mpa | |
Pressure of pilot system | 3.9 Mpa | |
Oil capacity | Fuel tank capacity | 400 L |
Hydraulic tank capacity | 220 L | |
Engine oil capacity | 25 L | |
Appearance size | Overall dimensions(L*W*H) | 9625×2990×3100 mm |
Width of platform | 2830 mm | |
Length of crawler | 4225 mm | |
Overall width of chassis | 2990 mm | |
Width of chassis | 600 mm | |
Track length on ground | 3462 mm | |
Crawler gauge | 2390 mm | |
Clearance under counterweight | 1050 mm | |
Min. ground clearance | 485 mm | |
Min. tail swing radius | 2890 mm | |
Working scope | Max. digging height | 9620 mm |
Max. dumping height | 6780 mm | |
Max. digging depth | 6680 mm | |
Excavation depth of 8 feet level | 6500 mm | |
Max. vertical wall digging depth | 5715 mm | |
Max. digging reach | 9940 mm | |
Min. swing radius | 3530 mm | |
Standard | Boom length | 1680 mm |
Arm length | 2910 mm | |
Bucket Capacity | 1.0 m ³ | |
Optional | Arm length | 5680 mm |
Bucket Capacity | 1.0 Earth working bucket | |
0.9 Rock bucket |
