9 Seats Electric Sightseeing Vintage Car For Amusement Park
- Category: Bus >>>
- Supplier: Suzhou Eagle Electric Vehicle Manufacturing Co. Ltd.
Share on (62134387344):
Product Overview
Description
Product Description
| Model | EG6090K | |
| System | 48V/5KW Series | 72V/5KW Series |
| Key Components | ||
| Battery | 8pcs T105 (185Ah@5hr) | 12pcs T105 (185Ah@5hr) |
| Motor | 5KW Chinese motor | 5KW Chinese motor |
| Controller | Curtis 1204M (325A @ 2 minutes) | Curtis 1205M (400A @ 2 minutes) |
| Performance | ||
| Passenger capacity | 9 | 9 |
| Range (loaded) based on flat road at a speed of 20km/h (km)* | ≥70 | ≥90 |
| Max. speed (km/h) | ≤25 | ≤30 |
| Minimum turning radius (m) | 7.2 | 7.2 |
| Max. climbing ability (loaded) | 15% | 15% |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
| Max. loading weight | 720kgs | 720kgs |
| Net weight | 1050kgs | 1180kgs |
| Dimensions | ||
| Overall dimensions (mm) | 4930*1610*1920 | |
| Min. ground clearance (mm) | 120 | |
| Wheelbase (mm) | 3500 | |
| Front wheel tread (mm) | 1385 | |
| Rear wheel tread (mm) | 1385 | |
