Product Overview
Description
UNI T UT210E TRUE RMS Digital Clamp Meter AC DC Multimeter Auto range Current Clamp Pincers Voltmeter Ammeter Ohmmeter VFC NCV
Product Description
Features:
1. VFC, low pass filter
2. NCV
3. Ergonomic and lightweight
4. Auto range, 2~3 times/s sampling rate
5. True RMS
6. ZERO mode
7. LCD backlight, data hold
8. Auto power off, low battery indication
3. Ergonomic and lightweight
4. Auto range, 2~3 times/s sampling rate
5. True RMS
6. ZERO mode
7. LCD backlight, data hold
8. Auto power off, low battery indication
Specification
Specifications | Range | UT210E | ||
AC current (A) | 2A/20A/100A | ±(2.5%+5) | ||
DC current (A) | 2A/20A/100A | ±(2%+3) | ||
AC voltage (V) | 2V/20V200V/600V | ±(1%+3) | ||
DC voltage (V) | 200mV/2V/20V200V/600V | ±(0.7%+3) | ||
Resistance (Ω) | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ | ±(1%+2) | ||
Capacitance (F) | 2nF/20nF/200nF/2μF/20μF/200μF/2mF/20mF | ±(4%+5) | ||
Features | ||||
Display Count | 2000 | |||
Auto Range | √ | |||
Jaw Capacity | 17mm | |||
True RMS | √ | |||
Diode | Around 3.0V | √ | ||
V.F.C | √ | |||
NCV | √ | |||
Data Hold | √ | |||
Zero | √ | |||
LCD Backlight | √ | |||
Auto Power Off | Around 15 minutes | √ | ||
Continuity Buzzer | √ | |||
Low Battery Indication | ≤2.5V | √ | ||
Input Protection | √ | |||
Input Impedance for DCV | ≥10MΩ | √ | ||
General Characteristics | ||||
Power | AAA 1.5V × 2 | |||
LCD Size | 39.3mm × 26.5 mm | |||
Product Color | Red + Grey | |||
Product Net Weight | 170g | |||
Product Size | 175mm × 60mm × 33.5mm | |||
Standard Accessories | Test Lead | |||
Standard Individual Packing | Gift box, Carrying bag, English Manual | |||
