Main Features
* Max 300W Electrosurgical Generator, with mono-polar and bipolar function.
* Seven working modes: pure cut, blend1, blend2, spray coag, soft coag, bipolar coag, bipolar cut.
* Wide clinical applications, such as the general surgery, thoracic surgery, orthopedic surgery, cardiology, gynecology, urology(under water TUR), oncology, neurosurgery, etc.
* Microprocessor controlled,.With audible and visual indicators and errors codes during the process of outputting.
* Return Electrode Monitoring system and Power Peak System, minimizing the risk of tissue damage.
* Both hand and foot controlled.
* Separate power display and outlet socket for mono-polar cut, mono-polar coag, bipolar cut and bipolar coag, each output can be individually configured.
* The unit always remember the last setting when it turned off.
* Remote control function. The surgeon can adjust the outputs by power control ESU pencil.
* The ESU unit can be connected with laparoscope and endoscope, etc.
* Protection against over-voltage and over-current.
* Defibrillation protected.
* Convection refrigeration without ventilator.
* Mounted on a 4 wheels cart(optional).
* Meets the requirements of international safety standards EN60601-1 and EN60601-2.
Technical Specifications
Power: 220V±22V, 50Hz±1Hz(110V±11V, 60Hz)
Power rating: 1100VA±10%
