Cold press machine for woodworking machinery and door making 50ton pressure

Product Overview

Description

Cold press machine for woodworking machinery and door making 50ton  pressure

Technical specifications

	MJ50T	MJ50B	MJ80T
Max pressure	50T	50T	80T
Dimension of the platen	1250*2500MM	3050*1250MM	1250*2500mm
working speed	180 mm/Min	180 mm/Min	180 mm/min
total power	5.5KW	5.5KW	5.5kw
overall dimension	2860*1300*2350mm	3500*1800*1600mm	2860*1300*3400mm
stroke	1000MM	1300mm	1000mm

this machine is widely used by manufacturers who produce furniture, sound boxes, woodworking, upholstery, advertising boards, plastics, veneers, plywood, shaving boards, laminated boards and any other woodworking casting dies

Functions

1,Leveling and shaping for some kinds of plates.

2,Working quality to be good, pressing fast and efficient.



Details:





Features

1,Easy to operate, reasonable design, stable performance

2,fast and efficient pressing.

3,Emergency safety braking.

4,Trip limited device.

5,Automatic compression and unloading pressure function

6,Work-table height convenient for human body.

 Main market

Which have been exported to a lot of countrise and Regions . Sich as Europe , Russia, Southeast Asia . Middle East . North America  and south America , Australia .

Quality certificate

ISO9001 and  CE security certificate

Business terms :

Payment terms: TT or L./C with deposit

Delivery time : Within 30 days

Packing :plywood box
