Brush and broom machine

Product Overview

Description

 Brush and Broom Making Machine for househole cleaning use



Description:
Model	MX-4ADT002
NO. of axis	4 axis
Qty of heads	2drilling and 1 tufting
Application	Flat, curved ,radial and toilet brush
brush types	customized
Brush base materials	Plastic, wood
Filament materials	PP,PET, Nylon,animal hair plant fiber etc.
Dimeter of the disc	≤500mm; 600~800mm
Diameter of hole	4~6mm
The length of filament(outside the hole)	20~110mm
Colors of Brush Filaments	2 colors
Parameter:
Drilling and tufting Speed	4~6 holes/sec.
Power voltage, frequence	220/380v , 50/60HZ  (customer choose)
Main motor power	2kw
Air Source Input	0.4~0.5Mpa
Equipment size	1500*1300*1800mm
Weight	1000kg
Electrical parts:
Control System(PLC)	MEIXIN Chinese and English version
Touch screen	MEIXIN Chinese and English version
Main motor	SNMA
Servo motor	Maxsine
Relay	IDEC (Janpan)
Variable-Frequency	DELTA (Taiwan)
Safety Protection:	Schneider (France brand)
