Product Overview

Description


Product Description

PM2018S Digital meter multimeter auto capacitance standard

6000 Counts Digital Clamp Meter

Product details

Frequency40~1000Hz
Display Count6000 counts
PEAK ACA10-900A
Power supply2x1.5V AAA Batteries
Product Keywordsdigital meter multimeter,digital auto,capacitance standard digital multimeter
Specifications (PM2018S 6000 Counts Super Smart AC Digital Clamp Meter)
DC Voltage0.5 – 600.0V±(0.5% +3)
AC Voltage (40 – 65Hz)1.0 – 600V±(0.8% +5)
Resistance0 – 10MΩ±(0.8% +3)
Continuity<30Ω<30Ω
AC Current (40 – 65Hz)10mA – 400A±(2.5%+5)
400A - 600A±(3.0% +5)
Frequency40Hz - 1000Hz±(1.5% +5)
PEAK AC Current10 – 900A±(10%+3)
Features
DisplayDual display, 6000 counts
RangeAutomatic
ACA (AC + DC)6A / 60A/600A
DCV6V / 60V 600V
ACV (AC + DC)6V / 60V 600V
Resistance6KΩ/ 60KΩ / 600KΩ / 6MΩ / 10MΩ
Frequency (Clamp)1KHz
Frequency (Voltage)1KHz
Continuity√
V /Ω / A Auto Scan√
LPF (1KHz – 3dB)√
Peak Max√
Non-contact AC Voltage Detection (NCV)√
Data Hold√
Back Light√
Low-battery Indication√
Auto Power Off√
General Specifications
Power supply2 x 1.5V AAA Battery
Weight 250g
Size187 x 65 x 38 mm
Jaw size¢24mm
Safety Rating EN 61010-1, -2-030, EN 61010-2-033,
EN61326-1, CAT.III 1000V








Packaging & Shipping

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
