Product Overview

Description

 spiral duct forming machine can be directly on the material round duct making machine can be directly use with flange bending machine, sheet of same board using flange is essential with flange bending machine process of practical equipment, but also can be used as a general ruffled machine used as a general ruffled machine use.




Model
STFR-1500
Tube Diameter
100-1600mm
Tube Length
120-8000mm
Thickness
0.5-1.2mm(Galvanized steel) 0.4-1.0mm(Stainless steel)
Strip Width
137MM MAX
shear parte
roll shear/plasma shear(extra require)
uncoil
1200KG
Lockseam
Outside tube
Controlling System
PLC automatic control
Main motor power
16KW
Iron Mold
Yes
Speed
0-35m/min
Dimensions(L*W*H)
3400x1850x1500/2100*1200*1100
Detailed Images
