Поставщик японских грузовиков буксировщиков для продажи

Product Overview

Description

Japan Rollback Tow Trucks For Sale Supplier



Ⅰ. The Product Description



We provide various wreckers with different types of towing equipment such as Boom, Hook and Chain ("sling" or "belt lift"), Wheel lift (Spectale Lift), Flatbed ("rollback" or a "slide"), Integrated ("Self Loader" Snatcher, Quick Pick or Repo Truck), etc. ranging from 3MT to 20MT capacity.



For the flatbed tow truck, the basic equipment includes double sides operation devices, lifting arm, winch, checkered plate, assistant trolley, yellow alarm lamp, strap devices, etc.



For the flatbed tow truck, the slide-to-ground-flatbed is available and attachable baffles can be added. Also the straight or knuckle crane and buckets on the crane can be added.

The available chasses are of dongfeng,sinotruck,jac,jmc,faw,foton,forland,shacman,japan



The detail photos that introduce How to load truck, how to operate truck, how to produce the wrecker towing truck





One-drive two wrecker towing truck
The totalmass(kg)	8000kg, 15000 kg	Curb Weight(kg)	4950
Truck brand	Japan, Dongfeng, HOWO, Foton, JAC
Approach /   departure angle(°)	22/10	Front overhang /  rear overhang	1120/2450
Dimensions(mm)	7520X2320X2380
Number of axes	2	Maximum speed	90
Tire  Specifications	7.50-16,10.00-20	Number of tires	6
Front track	1685	Rear track	1600
Wheelbase	3800mm,4500mm, 5100mm	Axle load	2440/4055
Number of spring	11/9+7	Type of fuel	Diesel
Emission   Standards	Euro3
Engine parameters
Engine Model	CY4102-C3C	Engine Manufacturer
Engine  Displacement	5900cc, 9782cc	Engine power		130hp, 190hp, 260hp, 340hp,380hp
Chassis  Description	4x2 chassis, flat cab with air conditioner, six speed gear box, 4 cylinder diesel engine, with left/right hand drive optional.
Modified  Description	1. Equipped with hydraulic capstan,steel wire rope,3P3 folding ram plate. 2. Plate bearing trouble trucks on plate,rear dragging trouble trucks. 3. Equipped with rear working light,hydraulic capstan,tool kit,hand-washing box,supporting fork,supporting fork stand,chain hook,long-line warning lights.
Component	Basic composition:chassis,pump,plate,winch,hydraulic capstan,supporting fork,supporting fork stand,chain hook,long-line warning lights.
Purpose	This truck  is mainly used for road fault vehicle, urban peccancy vehicles and rescue, etc.
Product advantage	High quality with best price.

Towing Capacity Two Vehicles
Rated Total Capacity 12000 kg
Platform Biggest Load Bearing Quality 6000 kg
Lift Arm Capacity 6000 kg
Lift Arm Length 1300 mm
Thinkness of Plate 3-5mm
Length of Steel Line 25 m
Speed of Steel Line 10 m / min
Platform Size 5530x2300 mm
Platform Gradient 100
Platform Power Stroke 2680 mm
Common Accessories Lift,winch,lashing hook, auxiliary wheel,bundling belt,automatic cable pulley, alarm light, wheel housing, etc.





 Trust us

1.11 years manufacture experience, good at controlling our products' quality. Choosing us ,you choose professional supplier.

2.The good faith management is our philosophy,and welcome visits our company at any time.

3.According to your order, we provide suitable trailer.

4.We also provide rational packing and shipping program, let shipment save money and security.

Just trust us,you will get a satisfactory answer.





1. Does your company has your own factory?
- Yes, we have a factory ourselves,which is in this business for 12 years in China. Our factory is very famous

where is manufacturing various trailers in ShanDong, China.



2. Can you satisfy my special requirement?

- Definitely! We can make the trailers based on your requirement.



3. What’s your minimum quantity?

- Min.1set



4. How to trust us?

- The good faith management is our philosophy, and you are welcome to visit our company at any time.



5. What’s your payment term?

--- T/T: 30% deposit by T/T, 70% balance should be paid before shipment.

--- L/C: 100% irrevocable credit of letter.
