Product Overview
Description
KBT Concrete Pump with Mixer
Self Loading Concrete Pumps Mobile Concrete Mixer With Pump
Product Description
Concrete Mixer Pump Introduction:
1. KBT series Concrete Mixer Pump combines concrete mixer and concrete pump as one new concrete pumping machine with concrete mixer.
2. Concrete mixer is driven by two mixing motor and grinding wheel rotation, with uniform mixing, thorough discharging and stable performance.
3. Concrete pump has double cylinder hydraulic pump system with reliable performance.
4. Concrete Mixer Pump spare parts are from high quality products of famous brand.
Concrete Mixer Pump Features:
1. compact structure, flexible movement, easy operation and simple maintenance.
2. remote control with high automatic degree and easy operation, saving labor cost.
3. independent mixing system with even mixing performance and high working efficiency.
4. double cylinder hydraulic pump system with high pumping speed and high working efficiency.
5. advanced S-tube distribution valve, well sealing techinc, good sealing performance.
6. centralized lubrication system, low consumption of equipment parts, less maintenance cost.
Concrete Mixer Pump Application:
1. pump concrete, fine aggregates such as fine stone and mortar etc.
2. pump heat-insulated lightweight foamed cement, mortar floor heating, and self leveling for ground architecture.
3. pump plain concrete and fiber concrete in engineering construction.
4. pump refractory and thermal insulation material.
5. pump afforestation soil in ecological environment construction.
6. pressure perfussion for foundation piles, backfill in overbroken tunnels, railway slope supporting, and disaster management.
Concrete Mixer Pump Technical Parameters:
Item | Unit | KBT2006/JZM300 |
Theoretical output capacity | m³/h | 20 |
Max. output pressure | MPa | 6 |
Delivery cylinder | mm | 180×800 |
Oil tank capacity | L | 200 |
Outlet opening diameter | mm | Φ150 |
Inner dia. of delivery pipe | mm | Φ125 |
Pump motor power | KW | 11 |
Max. aggregate dia. | mm | 40 |
Pulling speed | Km/h | ≤8 |
Max. theoretical horizontal delivery distance | M | 200 |
Max. theoretical vertical delivery distance | M | 60 |
Concrete Mixer Type | JZM300 | |
Capacity of charge hopper | L | 500 |
Capacity of discharge hopper | L | 300 |
Agitator motor type | Y132S-4B5 | |
Agitator motor power | KW | 5.5 |
Agitator motor speed | rpm | 1440 |
Hoister motor type | YEZ32-4 | |
Hoister motor power | KW | 4.5 |
Hoister motor speed | rpm | 1380 |
Water pump motor power | KW | 0.75 |
Diameter of drum | mm | 1260 |
Drum rotary speed | rpm | 15 |
Charge hopper average hoisting speed | m/s | 0.3 |
Tread distance | mm | 2200 |
Dimensions | mm | 5500×2000×2500 |
Weight | Kg | 3500 |
Concrete Mixer Pump Details:
Related Products-C
 | |
Mini Concrete Pump * KS-6, KS-8 (11kw, 15kw) * Hydraulic Type
| Concrete Pump * KMB-15, KMB-20, KMB-25, KMB-30, KMB-40 * Hydraulic Type |
|
|
Concrete Mixer Pump *KBT2006/JZM300 KBT2506/JZM350 KBT2506/JZM450 * Hydraulic Type | Diesel Concrete Mixer Pump *HBT2008/JZC350 HBT1506/JZC350 * Hydraulic Type
|
|
|
Concrete Pump * KMB-6, KMB-8 * Hydraulic Type | Shotcrete Pump * KBS-6, KBS-8 * Hydraulic Type |
FAQ
1. Q: Which concrete pump should we choose?
A: To recommend the most suitable model, please tell us:
- Material: composition, max aggregate size
- Capacity (-m3/h) :
- Delivery distance (horizontally / vertically):
- Grouting pressure:
- Driven type: electric motor, diesel engine, pneumatic motor
2. Q: What is the vulnerable part? How many spares should we prepare?
A: After long-time running, the rubber piston and cylinder sleeve may get worn. We will offer some spares for free.
Referring to the service life of each part, we will put a rough estimate of requested spares according to your project scale.
3. Q: Can we have customized model?
A: Yes. Customized production and OEM production are available according to your actual requirements.
4. Q: Do i need technical skills to operate this machine?
A: Yes. Please read the Operation Instruction for some basic technical skills before operating this machine, and contact us if any operation procedure is unclear.
5. Q: What should we do if there are some problems with the machine?
A: The Operate Instruction will help with routine maintenance and common problems.
Also, you can contact us for technical instruction by email, instant messenger or live video etc.
6. Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
7. Q: How about the package?
A: The machine will be wrapped by plastic film and packed by fumigation-free wooden case along with spare parts.
8. Q: How to place an order?
A: Both online order and offline order are acceptable.
It is suggested to place online order with a Trade Assurance to get full protection for first order.
9. Q :How to pay for this order?
A: Generally, TT, 30% deposit 70% before shipment;
L/C at sight (high bank charge, not suggest, but acceptable);
100% TT in advance (especially for small amount and spare parts etc.)
Company Information
Henan Coal Scientific Research Institute Co., Ltd. was established in March 1979. In 1999, it was ranked among the first batch of 242 coal research institutes, and implemented localized management by Henan Province. In 2006, it was transformed successfully into a scientific and technological enterprise, and renamed officially as Henan Coal Scientific Research Institute Co., Ltd.
Achievements: As one of the standard setting unit of national shotcrete equipment industry, the company has obtained more than 170 research and development achievements, more than 110 technical consulting services, 82 technology awards and15 national invention patents and utility model patents.
Application: mining well project, hydropower engineering, highway (railway) tunnel, subway engineering, bridge and slope maintenance, air-raid shelter construction, municipal construction, environmental greening project, blast-furnace refractories spraying, etc.
