Egg carton mold factory for machine making egg trays
US $300.00-$1000
New Hot Sale Paper Cup Machine For Factory
- Category: Paper Production Machinery >>>
- Supplier: Wenzhou Qichen Industry& Trade Co. Ltd.
Share on (62323879983):
Product Overview
Description
Product Description
ZBJ-OC12 automatic paper cup machineis an automatic machine with multiworking station,which has the function of paper feeding, wall sealing, pre-heater, bottom knurling, top curling, counter and safer operation.
The Overseas After-sales Service Provided paper cups machine has long life. It makes both one-side and two-side PE-film- coated paper cups.
Specifications of paper glass machine: | automatic paper cup machine |
Model | ZBJ-OC12 paper cup machine |
Paper Cup Size | 3oz-12oz (mold exchangeable) |
Raw Material | One-side PE (polyethylene) film coated / laminated paper Ultrasonic machine can be produce single and double PE paper |
Suitable paper weight | 180-300 gsm |
Productivity | 70-90 pcs/ minute\t\t\t |
Power Source | 220V/380V 50Hz or other required |
Total Power | 3.3KW |
Total Weight | 2300KGS |
Package Size(L x W x H) | 2600x1200x1850mm |
Working Air Source | 0.4 Mpa, Air Out-put:0.6 m3/minute |
automatic paper cup machine | Making Double PE coated paper cups, need to buy an air compressor |
Supply Quality Disposable Paper Containers Making Machines & Lines:
PE film coated/laminated paper,
Flexo Roll Paper cup printing machine,
Paper Cup Blank Offset Printing Machine,
Roll Paper Cup Die Cutting Machine,
Paper Cup Forming & Making Machine,
Paper Bowl Forming & Making Machines,
Paper Bucket Forming & Making machines,
Double Wall Paper Cup Machines,
Ripple Cup Making Machine
Paper Cup Sleeve Forming & Wrapping Machine
Paper Cup Counting & Packing Machine,
Paper Cup Plastic Lid Forming machine,
Paper Cup Handle Making Machines
Paper Plate Forming Machine,
paper cup making machine prices,
Paper Food Pail Machine, Paper Noodle Box Forming Machine,
Paper Box Forming Machine, Burger Box Machine, Chips Box Machine,
Paper Boat Tray Forming Machine,
Disposable Paper Cups,
Double Wall Paper Cups,
Ripple Paper Cups, Corrugated Paper Cups
Ice Cream Paper Cups, Popcorn Paper Cups,
Coffee Paper Cups, Tea Paper Cups,
Paper Cup Making Line & Machines:
1, PE film coated paper;
2, Printing machine (Offset fan-blank print machine, Flexo roll print machine); print logo,
3, Die cutting machine, cut the printed paper to cup-fan blank,
4, Paper cup forming machine, make the cups,
5, Cup count & packing machine: count and pack the cups into plastic film bag, etc.
6, Cup plastic lid machine, make plastic lid/cover.
Machines for Make paper cups:
here are series models,
3~12oz paper cup,
ZBJ-X12 Paper cup machine, 60~70 cups/minute, (Advanced style).
ZBJ-OC12 Paper cup machine, 70~70 cups/minute, (Improved style);
ZBJ-G16 Paper cup machine, 100~120 cups/minute, (Leading Style);
12~16oz paper cup:
ZBJ-X16 Paper cup machine, 50~70 cups/minute,
16~22oz paper cup:
ZBJ-OC35 Paper cup machine, 55~80 cups/minute,
DTJ-64 Popcorn Super Paper Cup Machine, 25~30 cups/minute
Making super cups, Around 64oz
DTJ-135 Popcorn Super Paper Cup/Bucket Machine, 20~30 cups/minute
Making super cup, paper buckets, around 135oz.
Certifications
Detailed Images
automatic paper cup machine PLC system
PLC system is just like a computer. It is imported from Schneider France.It is easier and more convinient to control the machine by PLC.
automatic paper cup machine 125# gear box
We use 125 type gear box, which has two years warranty.Normally, 100 type gear box is used.v 125 type is much bigger and stronger than 100 type.v 100 type gear box, if used for one year, is easier to have problem.The gear box is very important to the machine. It control the whole machine, if there are some problems with these two parts, then, you have to change the gear box. In this case, the machine should be taken apart, because it is inside the machine. It takes much time, and sometimes you cannot install the machine correctly. So it is necessary to use better gear box.
automatic paper cup machine The frame of the machine
The frame of new machine is thicker which can bear more weight than thinner one. So when the machine works it is more stable.
automatic paper cup machine Self-lubrication system
We use a self-lubrication system in the machine, which reduces the friction between the parts. So the machine can be maintained without manually fueling.
Our Service
Sales Service automatic paper cup machine
* Machine guarantee for one year.
* Our company will provide you good after services. We can help you solve the problem through video, email, phone. 24 hours hot line.
* If needed, we can also let our engineer go to your country to solve the problem. We hope all the customer will satisfied with our machine and services.
FAQ
1, Are you trading company or manufacturer?
We are manufacturer, and also provide the business solution to all the friends.
2, Do you have quality certificate?
Yes we have CE, ISO etc.
3,What's the delivery time?
Around 20~30days, however, against the goods.
4, Can you help us to buy other goods?
Sure of that, it is our honor to work for you, and control the goods quality.
