High resolution 1080x1080 resolution 5 inch round tft lcd display

Product Overview

Description

High resolution 1080x1080 resolution 5 inch round tft lcd display





LCD type	tft lcd
Part No.	TST050FHBH-40
Display format	1080(W) × RGB × 1080(H)
Interface	MIPI
Base Color	Normally Black
Backlight	6 white LED
Outline dimensions	136.531x132.208x1.98
Active Area	127.008x127.008
Dots Pitch	0.021(W)×0.063 (H)
With/without TP	available to custom
Illumination mode	Transmissive
Mass	About:23 g
Operation temperature	-20C to +60C
Storage temperature	-30C to +70C









7 inch capacitive touch screen lcd	7 inch lcd module 1000 nits	800*480 RTP 7 inch lcd module





1) Our standard tft lcd module size:  1.44", 1.77", 2", 2.2'', 2.4", 2.8", 3.2", 3.5",  4.3", 5", 7", 8", 10.1".



2) Color TFT 2.4'' to 7.0'' LCD with ZIF FPC connector.



3) Delevoped 4.0''(3.97'') IPS LCD module with wide viewing angle



4) Delevoped 4.3'' IPS LCD panel, 480x272 resolution.



5) 4.3" MCU interface TFT LCD module with SSD1963 controller.



6) 3.5" transflective sunlight readable TFT.

7) Standard 3.2'', 3.5", 4.3'', 5", 7" LCD  with CTP.



8) 2.4'', 2.8'', 3.2'', 4.3'', 5.0'', 7.0'' LCD display with touchscreen coverlens.



9) High brightness TFTs with Anti-reflective film with good performance under sunlight.



10) All common TFTs with Oflim can be with wide viewing angle, close to IPS panel & same as MVA glass















1. Replacement within 30 days after the shipment of products from us due to products' problems.
2. We can print your logo and stick your model No.on the cameras.
3. We have long cooperation with many shipping companies and our export volume is large. The shipping companies can offer us good discounts.
4. Professional technician supports. We have a good after-sales service team to solve your problems in time.
5.All goods will be inspected and tested before shipment.
6.Customer`s satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Trademanager or Email. It will be responded within 24 hours.









TEAM SOURCE DISPLAY ( TS DISPLAY) was established in 2004. Head office located in Shenzhen China.

TSD business scope covers LCD / LCD Module development, single-chip production and materials processing.

In a span of six years, we have developed thousands of LCD and LCM products for telecom, consumer electronics, medical equipment and other applications


We follow a people-oriented, quality and customer-first approach in all of our dealings. That is why we maintain a clean environment which is conducive for working and take the environment into account during the manufacturing process. Find out more about the benefits of working with us. Contact us today for any of your LCD / LCM projects and requirements.
