Notching machine mainly divided into angle-fixed notching machine and angle-adjustable notching machine, performance characteristics are as follows:
1) Compact structure, mechanical structure ensures the machine rigidity, with solid guide to ensure the best cutting accuracy and the cutter life.
2) Pedal switch control, easy operation; manual and cycle work modes are available for your choice.
3) Calibration indicates angle, through hand wheel adjust the angle, very convenient.
4) Stroke is adjustable, improve the cutting speed
5) Equipped with cutting length ruler, can adjust the position of positioning stopper, and set the cutting length
6) Polished workbench surface, smooth and level, not hurts workpieces
7) The cutter is suitable for cutting CS (Carbon Steel) and SS (Stainless Steel)
8) Equipped with material pressing foot to prevent plate from distorting and deforming
9) Plastic protective cover avoid contact with the cutting parts, ensure the safety of operators and equipment
10) Guide column automatic lubrication system reduces maintenance needs
WHAT FEATURES OF OUR ANGLE NOTCHING MACHINE ( MODE 1: FIXED ANGLE ) ?
● Hydraulic under move style ● Angle 90 Degree ● It can adjust the blade clearance according to the plate thickness ●Single-step or Multi-steps ● Lubrication all together ● Affordable price and high efficiency ● Big amount and stock
WHAT FEATURES OF OUR ANGLE NOTCHING MACHINE ( MODE 2: ADJUSTABLE ANGLE ) ?
●Hydraulic under move style ● Adjustable Angle From 30 to 140 ● It can adjust the blade clearance according to the plate thickness ●Single-step or Multi-steps ● Lubrication all together ● The angle is adjustable in chain. ● Affordable price and high efficiency ● Big amount and stock
Model
4*250
6*250
Max.Plate Thickness (mm)
Mild steel
0.5-4
0.5-6
Stainless steel
0.5-2
0.5-3
Max.Plate Length (mm)
250
250
Cutting Angle Range (°)
90
90
Travel Times (n/min)
35
35
Worktable Height (mm)
850
850
Motor Power(Kw)
4
4
Outline Dimensions
910*760*1050
950*820*1150
Weight
680
750
Product Details
Certificate
Company Introduction
Packing & Delivery
FAQ
1.Q:Where is your factory? How can I get there?
A:You can fly to NanJing LuKou airport directly, we will pick you up in the airport. All our customers, both inland and abroad, warmly welcome to visit us!
2.Q:How do you ensure quality in the factory?
A:Quality culture.:We always attach great importance to quality control from the beginning to the end. Our factory has obtained ISO, CE certification.
3. Q:How can I pay?
A:You can pay by T/T, Western Union, MoneyGram, Paypal; 30% deposit; pay off the 70% balance before shipment.
4. Q:How long to produce ?
A:Delivery time:15 days.
5. Q:Minimum order quantity?
A:1 set
