CNCHK- 3 (Vertical blade) is the solution to replace any punch machine! The table is 6200x3200x2300mm(244"x126"x 90"), the block size or the layers of foam can also be 3000x2300x1300mm(118"x90"x51").
Weight(T)
2.1
Full Power
9KW,380V,50HZ
Size(mm)
6000*3200*2300
Max foam size(mm)
3000*2300*1300
Blade size(mm)
1600*3*0.5
Servo system(r/min)
2400-2800
Max cutting Speed(m/min)
0-6.3
Admissible error(mm）
±0.5
Min cutting size(mm)
5
Size Information
Size Chart of This Design
Weight(T)
2.1
Type of CNC
Industrial computer
9Full Power
8KW,380V,50HZ
Display
LCD
Size(mm)
6000*3200*2300
Controlling module
Motion controlling card
Max foam size(mm)
3000*2300*1300
Operation system
Window 2000 or above
Blade size（mm）
1600*3*0.5
Programmable axis
X,Y,Z,φ
Servo system(r/mmin)
2400-2800
Step motor torque(N.m)
20
Max cutting Speed(m/min)
0-6.3
Min cutting radius（mm）
10
Admissible error(mm)
±0.5
Self-test system
Installed
Min cutting size(mm)
5
Blade alert
Installed
Packing&Shipping
Packaging Details:Protective film + Corrugated paper + Metal frame+Wooden case.
