Bridgelux LED Chip 10W 20W 30W AC COB LED Module Driverless cob led
- Category: COB LED >>>
- Supplier: Shenzhen Huanyu Dream Technology Co. Ltd.
Share on (62350788390):
Product Overview
Description
Specification
Model No | HY01917-57D3-1204B | Current | 600mA | ||
Efficiency | 90-130LM/W | Viewing angle | 120 degree | ||
Color Temp | 2700-20000K | Package | 19*19MM | ||
Voltage | 36-39V | Power | 12/18/24/30/36/42/48V | ||
Chip Brand | Bridgelux/ Sanan | SDCM | ≤3 | ||
Lifespan | 100000H | Substrate material | Superconducting aluminum | ||
Applications | Too many lamps,mainly indoor lighting | ||||
Hot sale Filp COB Selection Guide | ||||||||||||
Part No. | Power | Size (MM) | Series& Parallel | Voltage (V) | Efficiency | SDCM | ||||||
HYD6055-F57D3-4358B | 1200W | 60*60mm | 43S58P | 130-150V | 90-150Lm/w | ≤3 | ||||||
HYD3834-F57D3-3630B | 500W | 38*38mm | 36S30P | 108-112V | 100-150LM/W | ≤3 | ||||||
HY02823-F57D3-1040B | 200W | 28*28mm | 10S40P | 30-34V | 90-150Lm/w | ≤3 | ||||||
HY02823-F57D3-1822B | 200W | 28*28mm | 18S22P | 54-58V | 100-160LM/W | ≤3 | ||||||
HYD4030-F5730D3-1040B | 200W | 40*40mm | 10S40P | 30-34V | 90-130LM/W | ≤3 | ||||||
HYF4030-F5730D3-1040B | 100W | 40*40mm | 10S40P | 30-34V | 90-110LM/W | ≤3 | ||||||
HYF4030-F5730D3-1040B | 200W | 40*40mm | 10S40P | 30-34V | 90-160Lm/w | ≤3 | ||||||
HYD2823-F5330D3-0913B | 200W | 28*28mm | 9S13B | 27-32V | 90-130LM/W | ≤3 | ||||||
HY01814-F65D3-1206B | 50W | 18*18mm | 12S6P | 36-40V | 90-160Lm/w | ≤3 | ||||||
HY01311-F60D3-1401B | 7W | 13*13mm | 14S1P | 42-45V | 90-130LM/W | ≤3 | ||||||
HY01311-F60D3-1401B | 15W | 13*13mm | 15S2P | 45-50V | 90-130LM/W | ≤3 | ||||||
HY01917-F50D3-2402B | 24W | 19*19mm | 24S2P | 72-76V | 130-150LM/W | ≤3 | ||||||
Related products
Introduction of item:
★1, AC COB,Flip chip COB
High Power 50W,100W,200W,500W,1200W.
★2, Normal COB chip
3W,5W,7W,12W,18,24W,30W,42W,48W,60W,80W
★High CRI 90-98Ra
★SDCM<3
★Superconducting aluminum
★Ceramics
★Bridgelux/ Sanan
Applications
The series mainly used indoors
10w 16w 20w 24w LED Module For Ceiling Light,Track Light
Applicable areas:
Applicable areas: Suitable for international football stadiums, golf course Basketball court, Professional competition venues such
as tennis courts; Suitable for fire search and rescue, Search, prison, Moving vehicles, Landmark building, Special fields such as
bridges; Suitable for airports, pier, Swimming pool, Tower crane, bridge, TV tower, Landmarks and other fields.
as tennis courts; Suitable for fire search and rescue, Search, prison, Moving vehicles, Landmark building, Special fields such as
bridges; Suitable for airports, pier, Swimming pool, Tower crane, bridge, TV tower, Landmarks and other fields.
Application lamps:
Application lamps: Stadium lights Long-distance projection lamp Outdoor high pole light Tower chandelier Fish light Searchlights,
etc.
etc.
Packaging & Shipping
Company Information
Our Advantage: Own the LED special dust-free, anti-static workshop.Formed a number of world-class United States ASM automaticmachine crystalline solid,ASM automatic soldering machines, H120 automatic LED light colour scanner 100% sure our quality is best.
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 1-3 days, mass production time needs 3-7 days according order quantity .
Q3. Do you have any MOQ limit for led light order?What's the Payment way ?
A: MOQ is 100pcs for each model. We accept T/T Paypal and Western Union three ways payment.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 1-3 days, mass production time needs 3-7 days according order quantity .
Q3. Do you have any MOQ limit for led light order?What's the Payment way ?
A: MOQ is 100pcs for each model. We accept T/T Paypal and Western Union three ways payment.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
