Soft finish Stenter machine Heat setting Drying Wet Fabric

Textile Softening Drying Spreading machine

Application and advantages:

The machine is applied for the finishing of Acrylic, cotton, polyester, viscose, wool, polyester etc. fabrics, so that the finished fabric has stable size, smooth feel, softness and soft gloss.

The machine is composed of three sets of equipment. The three sets of equipment are equipped with automatic synchronizing device. Each machine can also be operated separately. The equipment is rotated by frequency conversion control. high efficiency, convenient operation, power saving, steam saving and provincial auxiliary. It greatly reduces the working intensity of people than the previous operation.

Technical Data:

Working Width: 1800mm,2000mm, 2400mm, 3000mm, can be customized

Speed:0~40m/min.

Roller Diameter:340mm

Drying cylinder Diameter:570mm

Felt guide band width:1700mm

Steam pressure: 0.5Mpa

Total power: 12KW

Dimension:(L*W*H) mm

Vertical type: 8000*3200*3400 (if 8 roller), *4000(if 10 rollers), *4650(if 12 rollers)

Horizontal type: 11500*3200*2550

Weight:about 3500kg

Shipping

1)By sea

We have big stable shipping agent, can do with FCL or LCL

1.Provide on-site installation services for the new machine.

2.Provide training to operators for free.

3.Provide one year warranty for key components.

4.Lifetime paid maintenance.

Detailed reference contract.
