High power uv led chip cob led 20w 30w 50w 365nm 390nm uv led curing chip
- Category: COB LED >>>
- Supplier: Shenzhen Yingfeng Opto-Electronic Co. Ltd.
Share on (62410896502):
Product Overview
Description
| Order Code | Voltage (V) | Peak Wavelength (nm) | Radiant Power (mW) | Radiation Intensity (mW/Sr) | Current (mA) | Half Width (nm) | Angle (0) |
| HYF120X43B365AGD16A | 13-16 | 365-370 | 15000-20000 | 10540 | 2800 | 9 | 90 |
| HYF120X43B380AG-D16A | 12--14 | 380-390 | 15000-20000 | 13304 | 2800 | 12 | 90 |
| HYF120X43B390AG-D16A | 12--14 | 390-395 | 15000-20000 | 12650 | 2800 | 18 | 90 |
| HYF120X43B400AG-D16A | 12--14 | 395-405 | 15000-20000 | 10122 | 2800 | 18 | 90 |
| HYF120G45P470AG-D16A | 12--14 | 465-475 | 4000-6000 | 5957 | 2800 | 25 | 90 |
| HYF120G45P480AG-D16A | 12--14 | 480-490 | 4000-6000 | 5685 | 2800 | 30 | 90 |
| HYF120O40N500AG-D16A | 12--14 | 495-505 | 3000-4000 | 4276 | 2800 | 26 | 90 |
| HYF120G45P530AG-D16A | 12--14 | 530-540 | 4000-5000 | 4836 | 2800 | 35 | 90 |
| HYF120F45N560AG-D16A | 10--12 | 550-570 | 1500-2000 | 6470 | 2800 | 40 | 90 |
| HYF120E42P590AG-D16A | 8--10 | 590-595 | 2000-2500 | 469.6 | 2800 | 20 | 90 |
| HYF120G42N600AG-D16A | 8--10 | 595-605 | 900-1100 | 2389 | 2800 | 15 | 90 |
| HYF120E42N630AG-D16A | 8--10 | 625-635 | 3000-4000 | 8212 | 2800 | 15 | 90 |
| HYF120E42N660AG-D16A | 8--10 | 650-670 | 9000-11000 | 42839 | 2800 | 17 | 90 |
| HYF120G42N670AG-D16A | 8--10 | 660-680 | 6500-7500 | 135582 | 2800 | 20 | 90 |
| HYF120G42N680AG-D16A | 8--10 | 680-685 | 9000-11000 | 12831 | 2800 | 25 | 90 |
| HYF120G42N700AG-D16A | 7--9 | 700-710 | 6000-7000 | 325 | 2800 | 22 | 90 |
| HYF120E42N730AG-D16A | 7--9 | 730-750 | 7000-9000 | 4015 | 2800 | 22 | 90 |
| HYF120L42N760AG-D16A | 6--9 | 750-770 | 6500-7500 | 2334 | 2800 | 22 | 90 |
| HYF120L42N780AG-D16A | 7--9 | 770-790 | 6000-7000 | 2434 | 2800 | 22 | 90 |
| HYF120E42N850AG-D16A | 5--7 | 840-860 | 9000-11000 | 4015 | 4000 | 35 | 90 |
| HYF120E42S850AG-D16A | 10--12 | 840-860 | 12000-15000 | 5464 | 4000 | 35 | 90 |
| HYF120E42N940AG-D16A | 5--7 | 930-950 | 7000-9000 | 3664 | 4000 | 45 | 90 |
| HYF120E35S805AG-X16A | 10-13 | 800-810 | 2500-3500 | / | 2800 | 15 | 60 |
| HYF120L42N970AG-D16A | 5--7 | 970-980 | 5000-6000 | 2077 | 2800 | 35 | 90 |
Warm Tip:The above parameters are for reference. Wavelength Angle, PCB can be customized according to requirements
Applications
Our products are widely used in various applications such as medical, life science, industrial Equipment, non-destructive testing, and analytical equipment.
