ferrite tile for EMC rf 10m and 3m chamber

Product Overview

Description

Ferrite Tile Size

·        Base size: 100*100mm

·        Standard height: 5.2mm, 6.7mm

·        Diameter of bore: 10mm





Ferrite Tile Application

·         Used for EMC chamber

Based on the principle of having complex magnetic permeability equal (or nearly equal) to complex dielectric constant. Materials with this property exhibit an impedance equal to that of "free space" and therefore do not reflect radiated energy at normal incidence.

  Ferrite Tile can provide 10dB - 25dB of absorption between 30MHz and 1GHz. Tiles are thin (approximately 0.26 inches), but can be heavy (roughly 10 lbs per square foot).



Size for EMC chamber ferrite tile

·        Base size: 100*100mm

·        Standard height: 5.5mm, 6.7mm

·        Diameter of bore: 10mm

Application for EMC chamber ferrite tile

Used for EMC chamber

Initial permeability	5500
Relative loss factor	15 at 0.1MHz
Saturation flux density	280(1194A/m)
Remanence	180
coercivity	3
Relative temp.factor	3
Curie temp.	90
Density	4.85*1000
Resistivity	100



30MHz	-25.5dB
100MHz	-38dB
300MHz	-19.5dB
500MHz	-16dB
700MHz	-12dB
1000MHz	-10dB
