2018 Asphalt Pavers 5300 Conveyor Paver for sale
- Category: Pavers >>>
- Supplier: EL KARMA TRADING
Share on (62437750173):
Product Overview
Description
| MODEL: | SRP90S plus | SRP95M plus |
| Base Paving Width (m) | 3-5.7 | 2.5 |
| Maximum Paving Width (m) | 9 | 9.5 |
| Maximum Paving Thickness (mm) | 350 | 350 |
| Paving Speed (m/min) | 0-18 | 0-18 |
| Travel Speed (km/h) | 0-2.4 | 0-2.4 |
| Hopper Capacity (t) | 15 | 15 |
| Theoretical Productivity (th) | 850 | 850 |
| Camber Adjustment(%) | -1 - +3 | -1 - +3 |
| Climbing Ability (%) | 20 | 20 |
| Vertical Flatness (mm/3m) | <2 | <2 |
| Horizontal Slope Error (%) | ±0.02 | 0.02 |
| Density Distribution Error (%) | <5 | <5 |
| Heating Method | Gas heating | Gas heating |
| Lubrication Method | Centralized Lubrication | |
| Diesel Engine | Deutz BF6M1013EC | BF6M1013EC/ Shangchai SC8D190G2B1 |
| Power 0utput | 148 | 148/140 |
| RPM | 2300 | 2300 |
| Screed | AVS9030D | DVM9525Q |
| Vibration Speed (r/min) | 0-1470 | 0-1470 |
| Vibration Distance (mm) | 4 | 3 ,5,7.9 |
| Secondary Vibration Distance (mm) | - | 0,3,6,9,12 . |
| Vibration Frequency (Hz) | 0-50 | 0-50 |
| Machine Weight (t) | 24 | 22 |
| Maximum Operating Weight (t) | 29 | 30 |
| External Dimensions LxWxH(mm) | 7800x9000x3800 | 7300x9500x3800 |
| Transport Dimensions LxWxH(mm) | 7800x3000x3360 | 7300x3000x3360 |
