Customization High-altitude Ladder Loading Truck Operation Truck
US $26600-$36600
SHACMAN F3000 8X4 самосвал Горячая продажа в Бангладеш
- Category: Trucks >>>
- Supplier: Oriemac Machinery & Equipment (Shanghai) Co. Ltd.
Share on (62446008259):
Product Overview
Description
Company Profile
Specification
SHACMAN F3000 8×4 DUMP TRUCK | ||
Cab | F3000 Cab,Single bed,Air conditioner | |
Dimension(Lx W xH)(mm) | 10329×2500×3450mm | |
Total mass(kg) | 31000kg | |
Kerb mass(kg) | 14600kg | |
Rated mass(kg) | 15930kg | |
Payload(kg) | 40000kg | |
Approach / departure angel | 28/21 | |
Front/rear suspension(mm) | 14525/2029 | |
Max. gradeability (%) | 28 | |
Engine brand | Weichai Engine | |
Engine model | WP10.340E32,340hp | |
Rated output power | 250kw | |
Torque(N.m r. p. m) | 1250N.m/1200-1600rpm | |
Rated speed(rpm) | 2200rpm | |
Emission Standard | E-II | |
Fuel type | Diesel | |
Displacement(L) | 9.726L | |
Driving type | 8×4 | |
Axle number | 4 | |
Wheel base(mm) | 1800+3575+1400mm | |
Clutch | φ430 diaphragm spring | |
Gearbox | FAST 10JSD140,10 Forward&2 Reverse,Manual | |
PTO | QH50 | |
Front axle | 7.5T MAN 2×7500kg | |
Rear axle | 16T MAN 2×16000kg | |
Ratio | 5.262 | |
Steering | technology left-hand drive(LHD) | |
Type | 12.00R20,12+1pc | |
Tank capacity(L) | 380L | |
Max. speed (km/h) | 82km/h | |
Color | Optional | |
Cargo box size(mm) | 7400×2300×1500mm bottom10mm,side8mm | |
Lifting style | Front lifting(made in china) | |
