Forever 120mm CNC 5th axis rotary table for milling,Rotary tilting table,Cncrotary table
- Category: Table >>>
- Supplier: Shenzhen Forever Precision Technology Co. Ltd.
Share on (62474640386):
Product Overview
Description
Functional features
▲ large Japanese high-precision angular contact ball bearing is adopted to support the external load;
▲ adopt the original ultra precision gear transmission structure of Japan;
▲High torque, precision and rigidity
▲ adopt the original ultra precision gear transmission structure of Japan;
▲High torque, precision and rigidity
Size Information
Size Drawing of This Design
Detailed Images
Specifications/Model | Unit | YHM-120 | ||||
Diameter of turntable disk surface | In the meantime, it is necessary to120 | |||||
Table height | Level | Mm | 180/195 | |||
Center Height | 90° | Mm | 95/110 | |||
Total height | Level | Mm | 180/195 | |||
Diameter of central hole | Mm | 12H7 | ||||
WorkbenchT Groove width | Mm | 12H7 | ||||
Tilt angle | Deg | ±95°/±115° | ||||
Turntable end surface runout | Mm | 0.01 | ||||
Parallelism between the disk surface and the base surface of the rotating table | Mm | 0.01 | ||||
The center hole diameter of worktable jumps | Mm | 0.01 | ||||
Axial | - | Rotating axis (B Axis) | Tilt axis (A Axis) | |||
Minimum Setting Unit | Deg | 0.001 | 0.001 | |||
Indexing accuracy | Sec | 16 " | 16 " | |||
Repeated positioning accuracy | Sec | 3 " | 3 " | |||
Output load torque | Optional motor (General) | - | 400w | 750w | ||
Continuous/Maximum torque | N | 24/34 | 117/167 | |||
Total reduction ratio | - | 1:51 | 1:81 | |||
Maximum speed of rotary table | Motor speed 3000 turn | r.p.n | 48 | 48/37 | ||
Maximum workload | 0° Horizontal time | kg | 35 | |||
0°~90° Tilting time | kg | 26 | ||||
Turntable weigh | kg | 30 | ||||
