5" Superior Quality Skiful 115*1.0*22.2mm china cutting disc
US $0.10-$0.50
Cheap Composite Abrasive Centerless Grinding Wheels for Grinding &Polishing
- Category: Grinding Wheels >>>
- Supplier: HAIWEI DEVELOPMENT LIMITED
Share on (62485872785):
Product Overview
Description
Product Description
| Product Name | Centerless Grinding Wheels |
| Usage | Grinding &Polishing |
| Place of Origin | TAIWAN (R.O.C.) |
| Abrasive | Composite abrasive |
| Grit Size (JIS) | Composite abrasive 220#~3000#,GRIT SIZE CAN BE USED AS PER YOUR REQUIREMENT |
| Bonding Agent | Resin |
| Shape | Straight,Recessed one side,Recessed two sides |
Standard size of centerless grinding wheel ( unit : mm )
| D | T | H | ||||||
| 75 | 100 | 127 | 150 | 205 | 255 | 305 | ||
| 305 | * | * | * | * | * | 120.0 127 | ||
| 355 | * | * | 127.0 177.8 180.0 | |||||
| 405 | * | * | 203.2 228.6 | |||||
| 455 | * | * | * | * | 228.6 254.0 | |||
| 510 | * | * | * | * | 228.6 254.0 304.8 | |||
| 610 | * | * | * | 304.8 | ||||
