Vibratory Deburring Bowls Finishing Machine
US $750.00-$800.00
Alpha 100 Variable Speed Manual Grinding And Polishing Machine For Metallographic Specimen Preparation Wheel Diameter 203/254 mm
- Category: Metal Polishing Machine >>>
- Supplier: Trojan (suzhou) Material Technology Co. Ltd.
Share on (62506500066):
Product Overview
Description
Specifications
ALPHA-100 | ||
Working wheel | Wheel | Single Working Platen With Individual Control Panel |
Speed | 50-1000 rpm | |
Diameter | 8”-10”(203/254 mm) | |
Direction | Clockwise/Counter clockwise | |
Torque at 300rpm | 3 N.m | |
Electronic | Voltage/Frequency | 110V/60Hz, 220V/50Hz |
Rated power | 750W | |
Standby power | 15W | |
Rated current | 2.9A | |
Max. current at 220V | 5A | |
Water Supply | Max. pressure | 0.6MPa |
Diameter of inlet hose | Φ8mm | |
Diameter of flush hose | Φ10mm | |
Diameter of drain hose | Φ32mm | |
Recirculating filtering unit | 30L & 0.01um | |
Operation panel | Glass touch panel | Optional |
Keyboards press panel | Optional | |
Button press panel | Optional | |
Noise level | At idle running, at distance 1m | <40dBA |
Operating environment | Temperature | -20˚C - 60˚C |
Humidity | 0-95%RH | |
Dimensions | Depth-With-Height | 740x455x340 mm |
Weight | Net | 39Kg |
