Yanbixin, Китай, линия электропитания, черный пластиковый фильтр EMI EMC для бытовой техники
- Category: Passive Components >>>
- Supplier: Shenzhen Yanbixin Technology Co. Ltd.
Share on (62508423094):
Product Overview
Description
Item | EMI power filter |
Model | YB16T4-10A-Q |
Transfer Function | Low pass |
Package Type | Surface Mount |
Nominal Center Frequency | 10K-30MHZ |
Rated Voltage | 120V/250V |
Rated Current | 1~10A |
Temperature Range | 25 / 085 / 21 |
Operating Frequency | 50/60HZ |
Line to Line | 500VDC |
Line to Ground | 2250VDC |
MOQ, Price | Negotiable |
Lead Time | 12-25days
|
Yanbixin China supply power line black plastic EMI EMC filter for household appliance
Our Advantages
1.After years of efforts of the company's personnel, products successively obtained the cUL,
TUV,CQC, CE, ROSH certifications.
2.We have a professional R&D team; our aims is we won't let customers spend any extra money!
3.National high-tech enterprises, brand assurance, reliable quality, and we have the relevant
product certifications.
4.We cooperate with top scientific research laboratories to provide free EMC rectification technical
support, samples; and free conduction test.
5.Automation technology, scale production, great price,excellent, service, fast delivery! Free replacement
within three months, free maintenance within six years, life-long maintenance!
Product Description
Physical Dimensions
Electrical Schematic
Characteristics
(1) Voltage Rating............................................................................................115/250VAC
(2) Current Rating:
A.@115VAC............................................................................................... 20A RMS Max.
B.@250VAC............................................................................................... 20A RMS Max.
(3) Oprating Frequency:50/60Hz
(4) Leakage Current: each line to ground
A. 115VAC/60Hz........................................................................................... 0.5mA Max.
B. 250VAC/50Hz...........................................................................................1.2mA Max.
(5) Hipot Rating(for one minute)
A. Line to ground............................................................................................ 2250VDC
B. Line to line.................................................................................................. 500VDC
(6) IR: 50M ohm A7 500VDC any input or output to ground
(7) Temperature Range: -25℃~+85℃
Our Company
1.Customized:We have a professional R&D team; our aims is we won't let customers
spend any extra money.
2.Listed company:National high-tech enterprises, brand assurance, reliable quality, and
we have the relevant product certifications.
3.Rectification test: We cooperate with top scientific research laboratories to provide free
EMC rectification technical support, samples; and free conduction test.
4.Scale production:Automation technology, scale production, great price,excellent, service,
fast delivery! Free replacement within three months, free maintenance within six years,
life-long maintenance!
Working Environment
The Exhibitions
Our Patents
Our Certificates
Single Phase Filter:
cUL:20190321-E471748
TUV:B0899310001Rev.01
CQC:19001226449
CE:SZAIS180620005-01
ROHS:MMCRHRWM60371744
Three Phase Filter:
cUL:20190325-E502442
ENEC:ENEC-02580
CE:SZAIS180620005-01
ROHS:MMCRHRWM60371744
Our service
Sample
Sample Fee: Negotiate
Sample Time: 3~5 days
Payment
---Payment terms: Western Union, D/P, T/T,L/C
---Please remember to leave the correct contact information for delivery.
Packaging and Shipping
Packaging
Power Line Filter: CTN/300pcs
N/G W.: 13.5/14.3KG
Measures:0.565*0.285*0.225m
Shipment
---Shipping terms: DHL, UPS, FEDEX, TNT, EMS
---Port is Shenzhen or as requests.
GIVE US A CHANCE TO COOPERATE
WITH YOU!
