12KW mold temperature controller unit MTC with Siemens

Product Overview

Description

Model			MTC
			1205G			1210G			1210S			1220S			1230S			1210G-TS
Medium			Fresh Water
Max. Working temp.℃			120℃
Control Method			P.I.D control
Heater Capacity (KW)			6			9						12/18			18/24			9*2
Pump	Seal Method		Mechanical Method
	Motor Capacity(KW)		0.37			0.75			0.75			1.5			2.2			0.75*2
	Max.Pressure(Mpa)		0.28			0.38			0.22			0.24			0.26			0.38
	Max. Flow(L/min)		42			56			165			235			315			56
	performance	Flow Rate(L/min)	20	39	42	56	52	25	22	110	165	23	170	235	30	240	315	38	52	56
		Total Head(M)	28	21	6	10	21	38	22	20	6	23	20	7	26	20	7	22	21	38
Cooling method			Direct Cooling
Cooling Capacity (KW)			11									50						11*2
Pipe Size	circulation Line	Main Pipe	1inch
		Branch pipe	3/8"*2 direction			3/8"*4 direction												3/8"*8 direction
	Cooling Line		3/8"									3/4"						3/8"
Alarm			Phase Reverse,Medium Shortage,Pump Overload,Temp.Upper and lower limit,Over Heat
PowerSupply			AC380V 3PH 50HZ
Water pressure			(0.1~0.3Mpa)
Accessories			5M  Power Cable 5M
Dimensions(mm)			850*290*655			850*290*655			1070*310*695			1130*340*835			1130*340*835			1100*340*935
Net Weight (KG)			50			54			60			110			120			105



FEATURES of mold temperature controller

♦Maxium operating temperature:300℃

♦ high efficiency oil cycle pump,big flow rate,long servicfee life

♦ Hot water piping is single unit design extended to 4 inlet and 4 outlet separation tubes to avoid leakage.

♦ Rapid heating and cooling. Temperature kept stable at all times

♦ P.I.D. multi-stage temperature control system can maintain a mould temperature with accuracy of ±0.3°C,  saves above electricity 35%

♦ Equipped with high pressure protection, safety pressure relieving, automatic oil supplying and air        exhausting.



MITEX  Oil temperature control machine merit controls the warm scope big, thermal stability good, but needs the medium cost,has the greasy dirt, the heat conduction efficiency was inferior to the water temperature machine, this company newest development type, the useimport board style heat interechanger, has the compact structure , controls the warm scope to reach 350°C, rises to decrease  temperature the speed to be quick, control the warm precise characteristic. The machines are widely used in the following fields: the temperature of precise injection molding, roller calendering, plastic film production lines, extrusion production  lines, blowing bottle blowing and triplex rubber extruders.
