AC Ammeter 500/5A Class 1.5 Size 110*110mm
- Category: Panel Meters >>>
- Supplier: Yueqing Annai Electrical Co. Ltd.
Share on (62553873773):
Product Overview
Description
Product Description
The movement is mostly made of high-performance permanent magnet material; the case is made of intensive flame retardant PC plastic, of which resistant heat 130 degree. Using double insulation so that resistant voltage up to 5300V; using double dealed waterproof and multiple layers of security design, so it can be used for special environments. The product fits the relevant requirements in the marine standard.
Specification
Description | Type | Input Range | Overload | Accurancy | Others |
HL Series Square Circular Wide Angle Rectifier Type AC Ammeter | HL-T80-GL AC **A | 100mA-20A */1A, */5A | 1 times, 1.2 times, 2 times | 1.5 | Working frequency 50Hz/60Hz Scale: 250 degree |
HL-T110-GL AC **A | |||||
HL Series Square Circular Wide Angle Coil Type DC Ammeter | HL-T80-GC DC **A | 100mA-20A 50mV-150mV | Without overload | 1.5 | Working frequency 50Hz/60Hz Scale: 250 degree |
HL-T110-GC DC **A |
