This is our high quality and new technology forceps.We have the large advantage of the technology on this items.
We have totally more than 50 different heads for this forceps.
The cutting and bitting capability is fully better than other factory's
Meniscus Forceps Technical Parameter
1,Specification
1:handle 2:rod 3:head
Sheet 1—1 unit:mm
Meniscus Forceps
D
L
Maximum opening range of head
Tolerance±20%
3.9 ± 0.15
120 ± 5
45°
3.9 ± 0.15
160 ± 5
3.9 ± 0.15
180 ± 5
3.9 ± 0.15
220 ± 5
3.0 ± 0.15
90 ± 5
Head shape
upward(A2)
Width(D1) mm
Bending of head (A1)
Circular mouth
0°
5.5
/
Circular mouth/upward
15°
5.5
/
Square mouth
0°
4.8
/
Square mouth/upward
15°
4.8
/
Circular head
0°
4.8
/
Circular head/upward
15°
4.8
/
Square mouth/widen
0°
6
/
Square mouth/widen/upward
15°
6
Left curved rod
/
/
The rod to the left 20°
Right curved rod
/
/
The rod to the right 20°
Upward rod
/
/
The rod upward 20°
Straight rod
/
/
0°
Sheet 2—2 unit:mm
Meniscus Forceps
D
L
Maximum opening range of head
Tolerance±20%
3.9 ± 0.15
120 ± 5
45°
3.9 ± 0.15
160 ± 5
3.9 ± 0.15
180 ± 5
3.9 ±0.15
220 ± 5
3.0 ± 0.15
90 ± 5
2,Performance
2.1 Opening and closing performance: the opening and closing of the head shall be smooth, and there shall be no shaking that interferes with the user's use and no clamping stagnation when opening and closing the Tong rod.
2.2 Head fit: the two pieces of head shall be matched with each other without any wrong mouth. The mouth of the bowl shall be complete and aligned with each other when it is closed.
2.3 The meniscus blue pliers shall have good shearing force, the teeth of the pliers shall be clear and complete, and there shall be no missing teeth, hairy teeth and sharp edges; the upper and lower two pieces shall bite each other to cut four layers of A4 paper smoothly;
2.4 Withstand repeated operation performance: able to withstand repeated operation for 20 times without damage or fracture.
3,Surface roughness: the head of the surgical instrument shall not be greater than 0.4 μ m; the rod shall not be greater than 1.6 μ M.
4,Corrosion resistance: the corrosion resistance of surgical instruments shall meet the requirements of class B of boiling water test method in YY / T 0149-2006.
5,High temperature and high pressure sterilization tolerance: after sterilization, it can neither damage the product function nor produce corrosion.
6,Mark and label: there shall be clear and easy to recognize and permanently attached form mark and manufacturer on the product.
